Znc Die EDM Sinker Machine Dm450zk Machine

Product Description

ZNC Die EDM Sinker Machine DM450ZK Machine
Control SystemManual type: input current and parameters according your experienceAutomatic processing type: machine automatic processing according required roughness, machining area size and depthIntelligent editor type: the system will set parameters after you input electrode shape, electrode material, workpiece material, processing area size, roughness and depthSystem adjust parameters automatically if machining is not steadyAutomatic checking carbon deposition and adjust parametersMultiple set selections to process the thin slice and large-sized workpieceFire-prevention and liquid level control Metric and InchMachine ConstructionThe machine is designed by special CAD software featured good structure and high precisionZ axis adopt high precision SANYO DC servo motorX/Y/Z axis adopt Taiwan ball screwX,Y axis adopt high precision bearingOil pump imported from Italy with big powerIt suits to process cavity, hole and special shape by copper, graphite, steel, tungsten steel, hard alloy steel material
ZNC Die Sinking EDM DM450ZK Specification
Item DM450ZK
Machine Size 3260*1800*2500mm
Machine weight 1750kg
Table travel (X, Y, Z) 450*350*200mm
Z axis twice travel 250mm
Table size 700*400mm
Electrode plates to the table distance 680mm
Worktable loading weight 800kg
Work tank size 1080*660*400mm
Max Current 50A
Tank size 1350*800*480mm
Max processing efficiency ≥600 mm² / min
Minimum electrode wear ≤0.1%
Best surface roughness ≤0.2um Ra
Maximum electrode weight 60kg
Controller HQ-50C
Power 9KW
ZNC EDM Machine Controller
