Nonwoven Disposable Glove Making Machine

Product Description

Performance Characteristics
The machine use the whole aluminum as frame construction,The overall easy disassembly,no need painting on appearance,Electronic-control is touch screen man-machine interface operation,built-in production time,counting,a preset number of automatic shutdown, etc. Imported reducer with brake motor,speed regulation by frequency variation,frequency transformer adopts the Taiwan brand "SUNFAR",low voltage apparatus adopts "DELIXI",sensor adopts Japan "MORON",PLC JAPAN "Mitsubishi", Main Motor Taiwan "CHENGBANG",Touch panel TAIWAN "WEINVIEW".
The whole machine adopts Automatic cutting,no need hand shear.
Technical Process:

Nonwoven--Convey--Folding--Convey--Ultrasonic laminate--Convey--Cutting-Products convey--Stacking--Convey
Technical Parameter
1,Voltage:AC380V 50HZ
2,Power:4KW
3,Speed:50-80pcs/minute
4,Net Weight:500kg
Gross Weight:660kg
5,Dimension :4860*800*1500mm
Raw Material Requirements:
Material Width:450mm
Material Weight(thickness):60-100g
Quotes and payment
10.1payment: After 30% of the total value is paid in advance by (T/T),
The left 70% should be paid by (T/T) after you check up the finished
machine. And the cargo will be delivered after all the payment
arrives at our account.
10.2 The quote is valid: 30 days
10.3 Delivery Date: Within 30 working days after receipt of prepayment from customers
