Module spare parts 5466-316

Product Details

Product Description

Product Description
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands

5466-316

Remote in- and outputs (RIO580) Using the process bus type MVB, remote inand output units 500RIO11 can be connected to the REG216 terminals. The input and output channels can be extended to a large number by using the RIO580 remote input/output system. Installing 500RIO11 I/O units close to the process reduces the wiring dramatically, since they are accessible via fibre optic link from the REG216 terminals. Analog signals can also be connected to the system via the 500AXM11 from the RIO580 family: • DC current 4...20 mA 0...20 mA -20...20 mA • DC voltage 0...10 V -10...10 V • Temp. sensor Pt100, Pt250, Pt1000, Ni100, Ni250, Ni1000. Construction Hardware The REG216 equipment comprises two main assemblies which are physically separated from each other and linked by standard prefabricated screened cables: • Interfaces to the primary system (CTs, PTs and auxiliary relays), which provide DC isolation and a barrier to electromagnetic interference • Parallel bus and associated electronic units (e.g. analog inputs and data processors/ for signal conditioning and processing. The complete protection scheme comprises relatively few hardware modules allowing subsequent expansion of electronic units and the interfaces. 21 units of rack space is available per equipment frame. functions. The desired protection functions to suit the particular application can simply be selected from a comprehensive library using the personal computer. No knowledge of computer programming is required. All setting ranges are extremely wide to make the protection functions suitable for a multitude of applications. The following main parameters can be set: • Allocation of processing units • Input channel or channels • Pick-up setting • Time delay • Definition of the operating characteristic • Tripping logic • Control signal logic. Setting a corresponding parameter enables the protection functions to be "connected" to particular input channels. Digital input and output signals can also be internally combined logically: • The tripping outputs of each protection function can be assigned to channels of the tripping auxiliary relay assembly in a manner corresponding to a matrix. • The pick-up and tripping signals can be assigned to the channels of the signalling auxiliary relay assembly. • Provision is available for blocking each protection function with a digital signal (e.g. digital inputs or by using the tripping signal of another protection function). • External signals applied to the digital inputs can be processed in any desired fashion. • Digital signals can be combined to perform logical functions e.g. external enabling or blocking signals with the output signals of an internal protection function and then used to block one of the other protection functions.
