CNC heavy duty horizontal lathe machine
This series lathe is based on the international market and the latest development trend of CNC lathes with semi-closed-loop control of the popular CNC heavy-duty lathes, 1600mm wide flat bed guide way provide users with a larger workpiece load, it is the ideal mechanical processing equipment for production of large parts .
This series lathe bed is whole box-shaped three guide-way structure, adopting high standard cast iron (HT300) one molding casting, after the second aging treatment, it has the feature of stable performance; guide-way width (1600mm), good rigidity, anti-vibration ability.
It is equipped with protective device and emergency stop safety button, when the machine suddenly encountered a sudden power failure or other failures, due to the special design of the control circuit, it can be self-protection to ensure that the lathe and personnel safety.

SPECIFICATION	UNIT	AK-2200H	AK-2500H
Max. swing over bed	mm	2200	2500
Max. swing over cross slide	mm	1850	2200
Distance between centers	mm	4000-20000	4000-20000
Bed width	mm	1600(3 slideways)	1600(3 slideways)
Loading capacity	tons	25/32/40	25/32/40
Chuck diameter	mm	1600/1800	2200
Max. torque of chuck	KN.m	80	80
Spindle taper	-	1.7	1.7
Spindle speed range	rpm	0.8-160(stepless)	0.8-160(stepless)
Range of cross feed	mm/min	1-2000	1-2000
Cross travel	mm	725	725
Range of longitudinal feed	mm/min	1-4000	1-4000
Longitudinal travel	mm	4000-20000	4000-20000
Tool-post working position	-	V4	V4
Section of tool shank	mm	70x70	70x70
Max. cutting force of tool-post	KN	80	80
Tailstock quill diameter	mm	300	300
Tailstock quill travel	mm	300	300
Tailstock quill taper	-	100,1:7	100,1:7
Tailstock rapid feed speed	mm/min	3000	3000
Tailstock quill rapid feed speed	mm/min	664	664
Main motor power	kw	75	75
Rapid feed motor power	kw	1.5	1.5

Features:
The main mechanism is driven by the 75KW DC motor, using the method of adjustable magnetic regulation, adjustment voltage and hybrid speed regulating mode, the ratio is 1: 22.2, speed change is three steps, mechanical and electrical integrated speed ratio is 1: 200, spindle speed range is 0.8 ~ 160r / min and stepless speed change.
The spindle bore diameter is large, headstock adopts the split type structure, and the contact rigidity is improved after scraping. The spindle adopts the front and rear bearing structure, so that the radial and axial stiffness and rotation accuracy are high.
Heavy duty four-jaw chuck. Standard configuration has two steady rest, one is closed type, the other is open type.
The tailstock is composed of upper and lower body, the upper body is equipped with a sleeve, a spindle and a pressure sensor, and the lower body is equipped with a rapid moving mechanism.

MAIN CONFIGURATION & ACCESSORIES: FANUC/GSK/SIEMENS CNC system, 4-jaw heavy duty chuck, 4-station electric tool-post, Work lamp, Pilot lamp, Cooling system, Manual pulse generator (MPG), Dead centers, Automatic lubrication pump, Electric moving tailstock, Tools & tool-box, Leveling wedge & bolts, Operation manual (English).

OPTIONAL CONFIGURATION & ACCESSORIES: Other type tool-post, Steady rest, Roller support, Live centers, Air conditioner, Chip conveyor.

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
