Aquarium Structural Acid Silicone Sealant Dispersing Power Mixer
| US$55,000.00-59,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
QLF-1100L
Certification
ISO
Condition
New
Stirring Type
Spiral
Working
High Speed Mixer
High Speed
1450rpm
Vacuum Degree
-0.098MPa
Structure
Gantry Type
Lock of Vessel
Mechanical Manual Lock
Total Power
86kw
Dimension
L2430 X W1400 X H3423 (Mm)
Mixer Type
Planetary Mixer
Layout Type
Horizontal
Mixing Drum Shape
Disc
Operating type
Cycle Operating
Transport Package
Wooen Case
Trademark
GMK
Origin
Guangdong, China
Production Capacity
100 Unit/Month
Product Description
1. CHARACTERS1) Dispersing power mixing
2) High speed
3) Vacuum, cooling and heating function
4) No dead point
5) Suitable for PU sealant, RTV sealant, HTV sealant, Acrylic sealant
6) CN, ISO9001
2. SUMMARY
QLF dispersing power mixer is a kind of high-efficiency multifunctional mixer already proved by practice. It can meet the needs of users to quickly change working requirements during operation, and can custom-make various kinds of mixer to meet different viscosity materials on clients' requirements. Working capacity range from 5L to 3500L, power is designed according to viscosity of materials. It is widely used in silicone sealant, adhesive, cosmetics, chemical products, battery, foodstuff, pharmacy and plastic industries, etc. Dispersing power mixer has 3-4 different stirrers inside of vessel, including one low-speed stirrer revolving around vessel axis, and the other 2-3 high-speed stirrers rotating around its own axis at different high speeds to achieve complicated movement of strong shearing and kneading for materials inside of vessel.
The E-shaped scraper inside the equipment revolves around the vessel axis to scrape the materials adhering to wall and bottom for ideal mixing effects. The equipment is well sealed, can be vacuumized, with excellent exhaust and bubble removal effects. The vessel cover can be hydraulically lifted, and vessel body can move freely for ease of operation.
| MODEL | NOMINAL CAPACITY | VACUUM DEGREE | VESSEL TYPE | DISCHARGE MODE |
| QLF-5L | 5L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-10L | 10L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-20L | 20L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-50L | 50L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-100L | 100L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-200L | 200L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-300L | 300L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-600L | 600L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-1100L | 1100L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-1500L | 1500L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-2000L | 2000L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-3500L | 3500L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
| QLF-4000L | 4000L | -0.098MPa | Electric, steam, oil heating / oil, water cooling jacket | Plug / No neck valve |
