Square Column Gear Head Conventional Milling Machine ZAY7045FG
| US$1,051.00-1,400.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ZAY7045FG
Type
Worktable Milling Machine
Object
Tool
Structure
Desktop
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Integral
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
Normal Precision
Certification
GS, CE, ISO 9001
Condition
New
Table Size
800X240mm
Spindle Travel
130mm
Spindle Taper
Mt4/R8
Step of Spindle Speed
8o-1250rpm
Max Fax Mill Capacity
45mm
Transport Package
Standard Plywood Package
Specification
CE
Trademark
WMT
Origin
Anhui
HS Code
84592900
Production Capacity
300 Sets/ Month
Product Description
FeatureMilling and drilling machine:
Milling drilling,tapping boring, reaming
Head swivels ±90° verticaly
Spindle micro feed precisely
Adjustable gibs on table precision.
Accurate position, strong rigidity,powerful cutting Gear-driven type and square column
Main specification
| Model | ZAY7045FG |
| Max Face mill capacity | Φ45mm(1-3/4") |
| Max End mill capacity | Φ80mm(3-1/8") |
| End milling capacity | Φ32mm(1-1/4") |
| Max.distance from spindle nose to table | 450mm(17-3/4") |
| Min.distance from spindle axis to column | 260mm(10-1/4") |
| Spindle travel | 130mm(5-1/8") |
| Spindle taper | MT4 or R8 |
| Step of spindle speed | 6 steps |
| Range of spindle speed 50Hz | 80-1250 rpm |
| 60Hz | 95-1500 rpm |
| Swivel angleof headstock(perpendicularly) | ±90° |
| Table size | 800mm×240mm(31-1/2"×9-1/2" ) |
| Forward and backward travel of table | 800mm×240mm(31-1/2"×9-1/2" ) |
| Left and right travel of table | 175mm(6-7/8") |
| Motor Power | 500mm(20") |
| Net weight/gross weight | 1.5KW |
| Packing size | 880×770×1160mm |
Guarantee Terms: Complete service by free of charge within 13 months after B/L date Technical service will be given forever at any time. Any questions during operation, can contact us freely by email, or contact on line by Skype, WhatsApp, etc. Also can talk face to face during fairs. You will get response within 20 hours.
Machine pics.
