Best Quality China Wool Combing Machine, Wool Comber
| US$110,000.00-150,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
FB300
Spinning Method
Wool Combing
Processing Material
Wool
Producing Process
Spinning Equipment
Certification
ISO9001: 2000
Warranty
12 Months
Customized
Non-Customized
Condition
New
After-sales Service
One Year
Transport Package
Wooden Case
Specification
FB300
Trademark
NANTONG BRAUN
Origin
China
HS Code
8445122000
Production Capacity
50 Sets Per Month
Product Description
TECHNICAL FERTURES1 Speed:control by frequency:30~260cycles per minute2 Lowest speed: 30 cycles per minute
3 Main motor:FB300: 3 kW-1500rpm Controlled by frequency inverter
4 Suction motor:1.1 kW-2800rpm
Feed creel motor: 0.25kW - 1400rpm
Delivery motor: 0.25kW - 1400rpm
Coiler motor: 0.40 kW - 1400rpm
5 Feed load in g/m:300~500;16~24slivers
6 Feed grid inside width:400 mm
7 Feed comb number :9
8 Feed length:4.5~8.8mm
9 Feed comb pinned length:410mm
10 Nipper working width:516 mm
11 Circular comb diameter:152 mm
12 Circular comb pinned width: 440 mm
13 Front comb pinned width: 470 mm
14 Drawing-off rollers diameter:25/28 mm
15 Circular brush diameter:160 mm
16 Circular brush width :430 mm
17 Clothed doffer diameter:138 mm
18 Drawing-off apron: Inside length 580×Width 540×Thickness3.5 mm
19 Feed creel type:Ball creel or Can creel Refer to the sales contract
20 Delivery type: Can delivery Refer to the sales contract for size
FB300 MACHINE PLANS Machine and delivery
Type | Size mm | Weight kg | |||||||
| Φ | h | d | f | e | b | Machine | Delivery | Total | |
| TC710J | 700 | 1000 | 1832 | 392.5 | 683 | 1430 | 2650 | 255 | 2905 |
| TC712J | 700 | 1200 | 1832 | 392.5 | 683 | 1430 | 2650 | 300 | 2950 |
| TC810J | 800 | 1000 | 1832 | 392.5 | 683 | 1430 | 2650 | 255 | 2905 |
| TC812J | 800 | 1200 | 1832 | 392.5 | 683 | 1430 | 2650 | 300 | 2950 |
| TC1012J | 1000 | 1200 | 2037 | 607 | 783 | 1620 | 2650 | 505 | 3155 |
