China Popular New Type Full Auto Paper Cup Making Machine

Product Description

Machine Description
LF-110 Middle-speed paper cup forming machine is a machine that have double turntable, dual-segment high-performance with functions of automatic paper fan feeding, hot air heater side seal, cup top lubrication, automatic bottom paper feeding, curling artwork, automatic cup collect and stock. Can make cups both single PE and double PE, for cold drinks and hot drinks. This machine speed can reach100-120pcs/min.
Advantages:
1)The core components adopt open cam design, with gear motor.
2)Machine has full automatic lubrication by oil pump and filtration, more convenient for maintenance.
3)The hot air heating system make the bottom sealed in a short time and high sealing quality.
4)Control panel use touch screen, a clearer vision, the whole electrical appliances adopt imported configuration, have high generality and good performance, and facilitate equipment maintenance.
5)The machine is controlled by PLC, and has a encoder to control the working of ultrasonic, sensors, solenoid valve and so on, to make the running of each process more accurately.
6)Use new rotary type paper fan feeding system, instead of traditional linear bearing, to ensure machine performance more stable and faster machine speed.
Mail technical parameters

GENERAL POWER	16kw
PAPER REQUEST	150-350g/ M^2 (BOTH SINGLE PE & DOUBLE PE COATED PAPER)
POWER SUPPLY	220V50Hz/ 380V50Hz OR CUSTOMIZED
CUP SIZE	4-16OZ
SPEED	100-120PCS/MIN
WEIGHT	2500kgs
DIMENSION	2600*1400*1900mm

MAIN PART LIST:

Motor	Main motor	China ZHIBAO
	Knurling/ curling motor	China ZHIBAO
Configuration	guide rail	Taiwan HIWIN
	Straight line bearing	JAPAN NSK
	, cutting mold and knurling	Cr12MoV Quenching
	open cam	20CrMoTi Carburizing and quenching
	gear	20CrMoTi Carburizing and quenching
	bearing	JAPAN NSK
	Turnplate	Aluminium alloy 5A02
Electric elements	TOUCH SCREEN	DELTA
	PLC	DELTA
	ULTRASONIC	EVERGREEN Ultrasonic
	Hot air heater	Switzerland
	encoder	OMRON
	Frequency converter	DELTA
	Contactor (switch )	SCH NEIDER
	Sensor	PANASONIC(JAPAN)

AFTER SERVICE
1. Warranty: 1 year
2. The guide booklet will be sent with machine to guide the installation process works, adjust the whole machine, production, avoide or solve the
Problem which the buyer will face.
3. We will adjust the machine well for one week before the delivery, ensure the machine has the perfect performance.
4. We can dispatch technologists to buyer's factory, guiding installation, adjustment for a period, the buyer incharge of the salary, traffic fee, boarding and lodging, communication and each day 100USD living allowances.
5. We supply the free training of buyer, the training won't stop until the buyer control the whole leson! The cost of air ticket, boarding and lodging should provided by buyer.
6. We supply the consumable spare parts for free for one year use.
