New 0.01~0.02 (mm) Gooda Steel Box Manufacturer CNC Duplex Milling Machine
| US$50,000.00-180,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
TH-1000NC
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools, Surface Grinding
Movement Method
Linear Control
Control Method
CNC Type
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Cutting Capacity
100-1000mm
Certificate
CE & ISO9001
Processing Mode
Automatically
Finished Accuracy
0.015mm/300mm
Transport Package
Steel Box
Specification
4.2*5.1*2.7
Trademark
GooDa Manufacturer
Origin
Dongguan
HS Code
84596190
Production Capacity
600
Product Description
TH-1000NC CNC duplex milling machine/Double sides milling machine automatic millingMain Function:
CNC system once setting and automatic guides where work-piece loading place, automatic measurement, four- sides process, which can reduce working strength of operator and increase Productivity, maintain high accuracy for dimension, squareness and parallelism.
| Main Specifications of CNC DUPLEX MILLING MACHINE TH-1000NC | ||
| Items | Name | Specification |
GooDa CNC DUPLEX MILLING MACHINE TH-1000NC | TH-1000NC | |
Cutting capacity | Control axis number | 4 |
| Cutting capacity mm | 2*1.5 | |
| Cutting width mm | 100-1000 | |
| Worktable | Dimensions mm | 600*600 |
| Max loading weight kg | 2800 | |
| Spindle | Spindle speed(Infinitely variable speeds) rpm | 50-500 |
| Spindle power kw | 2*15 | |
| Spindle taper | NT50 | |
| Cutting diameter mm | 300 | |
| X axis | X/Y/Z axis motor power kw | 2.5/2.5/3.0 |
| Y axis | X/Y/Z Max feed speed m/min: | 10000/10000/10000 |
| Z axis | X/Y/Z Max cutting speed | 8000/8000/8000 |
| Accuracy | Squareness mm/300mm | 0.015 |
| Accuracy for dimension mm/300mm | 0.015 | |
| Tank capacity | Hydraulic oil tank L | 60 |
| Lubrication oil tank L | 3 | |
| Power | Power | AC380V/200 80KVA |
| Net weight | Machine net weight KG | 13000 |
Main part of CNC DUPLEX MILLING MACHINE TH-1000NC
| Sort | Name | Quantity | Origin | Remark |
| Machinery | Worktable ball screw | 3 | Taiwan HIWIN | Steady transmission,High accuracy, Wear-proof |
| Guide rail | 3 | Taiwan HIWIN | Good bearing Strong stability | |
| Main Spindle (Horizontal) | 2 | Taiwan POSA | Low noise, high strength, Taiwan famous brand | |
| Flexible stainless steel plate shield of worktable | 2 | Domestic | High strength, Strong durability, dust-proof, Protect the guide rail and ball screw. | |
| Base casting | 1 | HT300 | Good stability, excellent wear-ability | |
| Automatic lubricating machine | 3 | Domestic | Electronic-self-lubrication, Quantitative oil supply to the each part | |
| Oil line | 3 | Domestic | Copper tube | |
| Bearing | JAPAN NACHI | World famous brand, High accuracy, High quality | ||
| Electrical appliances | CNC system | 1 | Japan FANUC | Top brand of CNC |
| Servo motor | 4 | Japan FANUC | Top brand of CNC | |
| High precision rotary table | 1 | Taiwan Central Star | Taiwan famous brand, High accuracy | |
| Spindle motor | 2 | CTB/MK | Multitronic, Meet the requirements of different processing speed | |
| AC contactor | Schneider- | Famous brand, steady property | ||
| Relay | Schneider- |
Duplex cnc milling machine ,made in china,gained 38 patent certifications
12 years experience, 3years guarantee.
high efficiency, high accuracy , high quality.
GooDa CNC series milling machine are your best choice!
