Cheap Cold Milling Machine Xm130k

Product Description

XM Series milling machine is one of the main asphalt concrete road maintenance equipment, mainly used for large-scale highways, urban roads, airports, freight yard, etc for renovation of asphalt pavement. One-time removal of entire concrete overlay. It can also be used for cleaning protuberance, oil layers, retieulation and vehicle tracks as well as road trench, tunnel excavation. Cement road surface roughening and dislocation smothness.
The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation.
Performance and characteristic
The milling drum is driven by two four-link belts with automatic tensioning drvice.
The moving system is the four-wheel fully hydraulic driving. The differential lock makes uniform driving forces even on the slippery road surface.
The machine has the advantages of being suitable for different milling materials and milling depth, optimizing power output automatic adjusting function and implementing maximization of the productivity.
The brake system implements the travelling brake by the reverse dragging of the hydraulic system. The multi-disc typed brake is arranged on the rear wheel reducer to implement the parking brake.
The automatic depth control (selectable )adopts the contact-typed or non contact-typed sensor for detection with digitally displayed milling depth.

Model			XM130K
	Max. milling with	mm	1320
	Max. milling depth	mm	315
Milling wheel	Number of tools		112
	Drum diameter with tools	mm	980
Engine	Model		6CTA8.3-C260
	Rated power	kW	194
	Rated speed	rpm	2100
Specifications	Operating speed	m/min	0~ 30
	Travel speed	km/h	0~ 7
	Ground clearance	%	50
	Ground clearance	mm	≤200
	Operating weight	kg	20000
Volume	Fuel tank	L	280
	Hydraulic oil tank	L	160
	Water tank	L	780
Conveyor	Width	mm	600
Measurement	Overall machinery LxWxH	mm	5255×2480×3245
	Conveyor LxWxH	mm	7020×1030×900
Travel mode			Tire
