Blue Color Strong Clamping Force Full Automatic Injection Molding Machine

Product Description

Product Description
blue color strong clamping force full automatic injection molding machine injection moulding machine

Model	KBD2980
Injection weight	835g
Tie bars	620*620mm
Clamping force	2980 kn
Machinery weight	9ton
Machinery Size	6.3*1.66*2.37

Detailed Images
blue color strong clamping force full automatic injection molding machine injection moulding machine

Size Information
Machinery Details

ITEM			KBD2980
Injection unit	Unit	A	B	C
SCREW DIA	mm	60	65	70
SHOT VOLUME	cm3	791	928	1077
(THEORETICAL)
INJECTION WEIGHT(PS)	g	711	835	969
INJECTION PRESSURE	Mpa	168	143	123
SCREW SPEED	rpm	0-165
CLAMPING UNIT
CLAMPING FORCE	KN	2980
TOGGLE STROKE	mm	590
SPACE BETWEEN TIE BARS	mm	620*620
MAX.MOLD HEIGHT	mm	630
Min.MOLD HEIGHT	mm	230
EJECTOR STROKE	mm	135
EJECTOR TONNAGE	KN	70
OTHERS
PUMP MOTER POWER	Kw	30
HEATING POWER	Kw	19
MACHINE DIMENSION(L*W*H)	m	6.3*1.66*2.37
MACHINE WEIGHT	T	9

Related Products

Packing&Shipping
Standard Export Packing
After Sales Service

What we can do for you ?
1.we are online 24hours. 2.if machine have any problem , we can guide you to solve it online .
3. We have engineers who can install and debug at customer factories.
4.We can give you a guarantee for the quality of the machine for a long time.
5.We can help you load containers, including goods from other factories.
6.Most importantly, we can provide complete plastic molding solutions.
Company Introduction
Kebida Machinery is a professional plastic machinery manufacturing factory in Ningbo, China. We provide various types of injection molding machines and complete solutions. Has 17 years of manufacturing experience. We can be your best choice. Kebida Machinery welcomes you.
Our Services & Strength We can provide complete plastic molding solutions: from raw materials-injection molding machines-molds-packaging, etc.
FAQ
Q:How to choose injection molding machine?
A:The injection weight should be about 1.2× product's weight; The tie bar space should be bigger than the mold dimension; Contact
with us for more information.
Q:How to pay?
A:40% deposit T/T in advance, the balance 60% payment by T/T before delivery (we accept payment by T/T, L/C etc.)
Q:Is that possible for your company to send engineer to install machine for commissioning, even train our workers?
A:Yes, we can send our engineer to your factory for installing, commissioning, training. We have some engineers flying among
different countries for after sale service and technical support. As per experience, if everything OK usually 5-15 days is enough.
Therefore, before shipment, we need you to prepare invitation letter for visa. However, please be noted that all cost happened for
visa, travel, hotel should be paid in advance by customers. In addition, we cannot guarantee each visa is successful.
Q:If we buy your machines, is there any warranty?
A:Yes, definitely. Totally 24-months warranty after shipment for mechanical parts, hydraulic parts, electric components (The screw
just has 6-months). We are responsible for broken parts within 24-months. We will supply those parts in freeway but the possible
transportation cost should be paid by clients.
Q:What is different with A,B,C screw, What is the price different?
A:The screw model is designed for different material and requirements, the screw diameter Changes from small, middle and big.
There is no price difference in the price for choosing A/B/C screw types.
Q:How to choose the screw ?
A:For PC,Pa(Nylon)and other high viscosity material ,it's better to choose A screw .
For PP,PE,PS materials, better to choose B Screw .
For Recycled material , better to choose C screw .
Q:What's the delivery preriod after place the order?
A:Normally the delivery date will be in one month after receiving the down payment .
