Klt-E4mpf-Ov9281 V3.0 1MP Ov9281 Globaler Verschluss Mipi and Dvp-Schnittstelle Fester Fokus Kameramodul

Klt-E4mpf-Ov9281 V3.0 1MP Ov9281 Globaler Verschluss Mipi and Dvp-Schnittstelle Fester Fokus Kameramodul

US$14.00-16.00 100 Pieces (MOQ)

Basic Info.

Model NO.
KLT-E4MPF-OV9281 V3.0
Interface Type
Mipi and Dvp
Specification
120.00 x 10.00 mm
Origin
China
Production Capacity
500000 Pieces

Product Description

1MP OV9281 Globaler Verschluss MIPI and DVP-Schnittstelle Fester Fokus Kameramodul
Kameramodul Nr. KLT-E4MPF-OV9281 V3.0
Kameramodul Nr. KLT-E4MPF-OV9281 V3.0
Auflösung 1MP
Bildsensor OV9281 Globaler Verschluss
Sensorart 1/4"
Pixel Größe 3.0 um x 3.0 um
EFL 2.09 mm
F.NO 2.40
Pixel 1296 x 816
Betrachtungswinkel 146.0°(DFOV) 117.0°(HFOV) 67.0°(VFOV)
Linsenabmessungen 8.00 x 8.00 x 13.52 mm
Modulgröße 120.00 x 10.00 mm
Modultyp Fester Fokus
Schnittstelle MIPI und DVP-Parallel
Autofokus-VCM-Treiber-IC Keiner
Linsenmodell KLT-LENS-TRC-4037J1
Linsentyp 650 nm IR-Schnitt
Betriebstemperatur -30°C to +85°C
Gegenstecker DF30FC-24DS-0.4V
