High Quality Three Phase Energy Electricity Meter Power Monitoring System Meter Smart 3 Phase Energy Meter

Product Description

Energy meters are the basic part to measure the power consumption. It is used everywhere, no matter how big or small consumption it is. It is also known as watt-hour meter. Here we discuss the construction and working principle of induction type energy meter.To understand the structure of watt-hour meter, we must understand the four essential components of the meter. Type JH-EMBM Three-phase energy meter Single-phase energy analyzer can measure imported and exported energy or be programmed to consider only the imported one. Housing for DIN-rail mounting, with IP51 front degree protection.The meter with RS485 communication.
Product Benefits
Single phase energy analyzer
Class 1 (kWh) according to EN62053-21
Class B (kWh) according to EN50470-3
Accuracy ±0.5% RDG (current/voltage)
Direct current measurement up to 100AAC
Backlit LCD display (3x 8-digit) with integrated touch key-pad
Energy readout on display: 6 digit
Variable readout on display: 2 digit
Energy measurement: kWh and kvarh (imported/exported); kWh+ by 2 tariffs
System variables, kW, kvar, V, A, PF, Hz, kWdmd, kWdmd peak
Dimensions: 2-DIN module
Pulse output (optional, by open collector PNP)
RS485 Modbus port (optional)
M-bus port (optional)
