Automatic Production Line Laminated Wood for Soft and Hard Solid Wood, Particleboard, MDF Widely Used in Furniture, Wooden Doors,

Product Description

1,Application :
It mainly apply to laminated wood, particle board,door panel jointing, and solid wood, door pocket, door line banding, or other wooden block gluing etc.
1. High Timber Out turn : 5%-10% more on average compared to the general clamp carrier
2. High Efficiency : 1-3 mins to finish one board , especially processing in winter much more significant
3. Energy Saving :15-30 kw/h power consumption for 1 cbm board jointing
4. Low Labor Cost :feeding & discharging device of belt-conveyer , adding palletizing and gluing system for option to get more efficient as well
5. Heavy Frame : Using large-scale machine tool to ensure its verticality
6. Easy Operation: Touch screen HML, with a built-in operation instruction which including installation, operation, repair, maintenance etc.
7. Safety :Adding high sensitive spark protection circuit and make separated cabinet for HF parts
8. Good components :assorting Taiwan pneumatic tools mostly
9. The thinnest board of jointing is 6 mm at least, 80 mm max thickness
2,High frequency ComposerThis production line of heavy duty high frequency board jointing machine can compose a single length of 6 meters board.

	CGPB-28P	CGPB-46P	CGPB-65P	CGPB-83P	CGPB-91P
Working bench size	2500*1300mm	2500*1300mm	2500*1300mm	2600*1300mm	2300*1300cm
Thickness of board	10-50mm	10-80mm	10-150mm	10-180mm	15-200mm
Upper pressure	9T	13T	13T	13T	21T
Back pressure	19T	33T	52T	70T	70T
Outer dimension(L*W*H)	8700*2300*2300mm	8700*2350*2300mm	8700*2350*2300mm	8800*2350*2300mm	8800*4400*2300mm
Weight	3.5t	5.5t	6.5t	7t	9t
Feeding mode	Auto	Auto	Auto	Auto	Auto

3,Machine detail show:
4, Machine characteristics:
5, Sample Show
End product show:
