Factory Price SFP28 10g 25g Lr 1310nm LC Interface with Ddm SMF 10km 20km SFP28 Optic Trancceiver Module SFP 25g

Product Description

Product Description Why Choose us 1. A free sample of our Stock Products
2.You can know the factory direct price
3.Delivery within 1~3 days for most models
4. Compatible with Most all the brand equipment
5.The best quality and custom service you ever found
6. After-sales 2-year warranty and lifetime technical support
To inquire about details and prices, please contact us! Features
1 Compliant to INF-8077-XFP MSA
2 Data Rate from 9.95 Gbps to 11.3Gbps
3 1310nm DFB Transmitter, PIN Photodiode and TIA
4 SM 9/125um up to 10Km
5 Duplex LC connector
6 Built-in digital diagnostic monitoring functions
7 All-Metal housing for superior EMI Performance
8 Power dissipation < 1.5W, Single 3.3V power supply
9 Operating Case Temperature Standard: 0ºC~+70ºC
10 Protocol-independent,XFI Interface
11 Hot Pluggable
12 ROHS6 Compliant

Applications
1 SONET OC-192 SR-1&SDH STM I-64.1
210GBASE-LR/LW 10Gigabit Ethernet
310G Fiber Channel
10Gbps 10Km XFP 1310nm Transceivers is hot pluggable 3.3V small-form-Factor transceiver module. It designed expressly for high-speed communication applications that require rates up to 11.3 GB/s it designed to be compliant with XFP MSA. The module data link up to 10km in 9/125um single mode fiber.The optical output can be disabled by a LVTTL logic high-level input of Tx Disable. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with the partner.
Product Parameters Optical Module Transceiver: SFP ,SFP+ ,XFP, QSFP, DAC, AOC ,RJ45 etc.
Rate: 155M ,1.25G ,2.5G ,4.125G ,6G ,8G ,10G ,16G ,25G ,32G ,40G ,56G ,100G etc. ★★Send us an Enquiry to get a full catalog with prices★★

Part No.	Data Rate	Distance	Wavelength	Sensitivity	Connector	DDM	Work Temp.
SFP-10G-BX20	10G	20km	1330nm/1270nm	-15dBm	LC	Yes	0~70ºC
SFP-10G-BX40	10G	40km	1330nm/1270nm	-15dBm	LC	Yes	0~70ºC
SFP-10G-BX60	10G	60km	1330nm/1270nm	-20dBm	LC	Yes	0~70ºC
SFP-10G-BX80	10G	80km	1490nm/1550nm	-23dBm	LC	Yes	0~70ºC
SFP-10G-SR	10G	300m	850nm	-12dBm	LC	Yes	0~70ºC
SFP-10G-LR	10G	10km	1310nm	-15dBm	LC	Yes	0~70ºC
SFP-10G-ER	10G	40km	1550nm	-16dBm	LC	Yes	0~70ºC
SFP-10G-ZR	10G	80km	1550nm	-23dBm	LC	Yes	0~70ºC
QSFP-40G-SR4	40G	100m	850nm	-12dBm	MPO	Yes	0~70ºC
QSFP-40G-LX4	40G	2km	1310nm	-12dBm	LC	Yes	0~70ºC
QSFP-40G-LR4	40G	10km	1310nm	-12dBm	LC	Yes	0~70ºC
QSFP-40G-ER4	40G	40km	1310nm	-22dBm	LC	Yes	0~70ºC
QSFP28-100G-SR4	100G	100m	850nm	-11dBm	MPO	Yes	0~70ºC
QSFP28-100G-LR4	100G	10km	1310nm	-12dBm	LC	Yes	0~70ºC
QSFP28-100G-ER4	100G	40km	1310nm	-21dBm	LC	Yes	0~70ºC
QSFP28-100G-ZR4	100G	80km	1310nm	-28dBm	LC	Yes	0~70ºC
QSFP28-100G-CWDM4	100G	2km	1310nm	-12dBm	LC	Yes	0~70ºC

Detailed Photos
Certifications
FAQ
Q1: Are you a manufacturer?
A: Yes, we are a manufacturer who has a factory in Shenzhen . Welcome to visit!
Q2: What is your MOQ?
A: 1 piece is available. We can also provide free samples for our valued customers. Q3:Can you provide the OEM&ODM services?
A: Sure, we have the complete production line; we could do the production as per your request. Q4. Can I have a sample order for this product?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. Q5: How long is your delivery time?
A: Generally, it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock; it is according to the order quantity. Q6: Can I negotiate the prices?
A: Yes, we may consider discounts for multiple container loads of mixed goods. Q7: How much will the shipping charges be?
A:It depends on the size of your shipment and the method of shipping. We will offer the charge to you as you requested. If you have another question, please contact us. Packaging & Shipping
