(Dingchen-2100mm) Corrugated Paper Making Machine

Product Description

Perfect service: 1.technical consultation 2.Plant design 3.installation and test run 4.training engineers and workers 5.good and long time after-sale service The business process 1.send your requirements:raw material,capacity,paper grammage 2.we make the solution to you 3.come visit and negotiate 4.sign contract 5.first payment 6.production 7.pay spare money 8.delivery 9.installation ,training,test run 10.production consultlation We have a large scale of products regarding paper machinery, including: A.Pulping equipment (D-type hydrapulper, cleaner, DD refiner, pressure screen, screen basket, pulp pump etc.) B.Paper machinery (Tissue/Toilet paper machine, Multi-fourdrinier paper machine, head box, cylinder mould, dryer cylinder, roller etc.) C.Paper making finished devices (Paper calender, pope reel,size press, paper rewinder etc.) Meet customers' requirements and exceed customers' expects. We wish to found long-termcooperation with your company
2100mm corrugated paper making machine
(I).Technical parameter:

Raw material	Waste paper and pure wood pulp
Output paper	Kraft paper
Weight	130-300g/m2;
Capacity	20-25T/D
Net paper width	2100mm
Wire width	2450mm
Rail gauge	2900mm
Drive way	speed adjustment in AC frequency &processing transmission
Work speed	80-120m/min

(II). Main frame of equipments:

1.Cylinder part: 1250mmx 2450mm x 2900mm stainless steel plate style cylinder mould 3 pcs, 450mm x 2450mm x 2900mm couch roll 3 pcs, 450mm X 2450mm x 2900mm reverse roll 1 pc, rubber hardness HSD 80°±2,

2.press part: 600mmx 2450mm x 2900mm rubber roll 2pcs,rubber hardness HSD 92°±2,650mm x 2450mm x 2900mm natural marble stone roll 2 pcs, pneumatic loaded device.

3.Dryer part: 1500mm x 2450mm x 2900mm alloy dryer can 6 pcs, it is equipped with dry mesh device.

4.Calendar part: three rolls calender1set, bottom roll 400mm x 2450mm x 2900mm, Middle roll 250mm x 2450mm x 2900mm, Rearward roll : 300mm × 2450mm x 2900mm

5.Reeling part: 900mm reeling machine
Company Information
Zhengzhou Dingchen Machinery Co., Ltd., located in Central China, is a professional machinery manufacturer focusing on the R&D and production of paper making machines.Our products include paper making machines,pulp making machine,parts and paper converting machines such as kraft paper machines,corrugated paper machines,tissue/toilet paper machines,office paper machines, newspaper machines and so on. Our factory gathers and trains many essential technicians and management system to ensure all products meet the quality of ISO and update constantly!
Our products have been exported to many countries and regions, such as America, Egypt, India, Fiji, Iran, Ghana ,Paraguay, Russia, Syria,Pakistan, Tanzania, and Uzbekistan. Our products and services have won customers' consistent affirmations.have won customers' consistent affirmations.We have a large scale of products regarding paper machinery, including:A.Pulping equipment (D-type hydrapulper, cleaner, DD refiner, pressurescreen, screen basket, pulp pump etc.)B.Paper machinery (Tissue/Toilet paper machine, Multi-fourdrinier papermachine, head box, cylinder mould, dryer cylinder, roller etc.)C.Paper making finished devices (Paper calender, pope reel,size press,paper rewinder etc.)Meet customers' requirements and exceed customers' expects.We wish to found long-termcooperation with your companyTechnical Advantage1.Experienced producing team2.Advanced technological strengthProduct Advantage1.Through the international authentication2.The same material the most preferential price3.A lot of varieties for the customer to chooseService Advantage1.Technical consultation2.Project evaluation3.Detailed design of factory4.Installing and testing the whole production line5.Training engineers and workers6.Supplying spare parts for long timeThe business process1.send your requirements:raw material,capacity,paper grammage2.we make the solution to you3.come visit and negotiate4.sign contract5.first payment6.production7.pay spare money8.delivery9.installation ,training,test run10.production consultlation
