Skymard 8m3 100 110 130ton Large Mining Excavator Me105 Me106 Me130 with Breaking Hammer

Product Description

Overview
Skymard 8m3 100 110 130ton Large Mining Excavator Me105 Me106 Me130 with Breaking Hammer
The use of super power engine, strong power to meet the national four emission standards; 2, Equipped with integrated full electric control handle, more convenient operation; 3, The product is equipped with explosion-proof valve, the construction is safer; 4, A full range of standard automatic lubrication system, easy to maintain; 5, Increased engine and hydraulic oil independent cooling system, good temperature adaptability; 6, Fully electronically controlled main pump, main valve, fast response, power and working conditions more match.
Product Overview:
• Large capacity bucket and optimized devices that enhances operational efficiency significantlyat adverse miningenvironments and during complicated operations
• Good ergonomic design with low vibration and noise, wide and comfortable full view cab to provide stable operation
Product Description

Product Parameters

Mass of the whole machine(kg)	102000
Dourong (m3)	6.5-8
motor	2806IIIN
Rated power(kW)	570.5
Maximum Breakout Force(kN)	514
Average Specific Ground Pressure (kPa)	127.4
Travel speed (low/high) (km/h)	2.3-3.8
Gradeability (°)	35
Maximum digging radius (mm)	12530
Maximum digging depth(mm)	7110
Maximum unloading height	8040
Overall dimensions of the whole machine (transfer position) (mm)	13700×4510×5200
A-Maximum excavation range(mm)	12530
B-Maximum ground excavation distance (mm)	12210
C-Maximum digging depth(mm)	7110
D - Maximum excavation depth (2.44m) (mm)	6970
E-Maximum vertical digging depth (mm)	4700
F-Maximum digging height(mm)	12300
G-Maximum unloading height(mm)	8040
H-Minimum front turning radius (mm)	4990
