Hot Sale Desiccant Wheel Dehumidifier ZCS-3000
| US$10.00-50,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
ZCS-3000
Timing Function
With Timing Function
Function
Washable Air Filter, Automatic Humidistat Control
Type
Desiccant Dehumidifier
Transport Package
Wooden Case
Specification
ZCS-3000
Trademark
Fudair
Origin
Zhejiang, China
HS Code
84798920
Production Capacity
5000sets/Year
Product Description
| Main Parameters: |
| Model | ZCS-3000 |
| Process Airflow(m3/h) | 3000 |
| Reactivation Airflow(m3/h) | 1000 |
| Rated Dehumidification Capacity(kg/h) | 21.6 |
| Reactivation Heating Power(kw) | 18 |
| Process Fan Power(kw) | 3.0 |
| Reactivation Fan Power(kw) | 1.1 |
| Driving Motor Power(kw) | 0.1 |
| Installed Power(kw) | 22.2 |
| Overall Dimension(mm) | 2550*1000*1760 |
| Weight (kg) | 450 |
| Power Supply | 380V/3P/50Hz |
| Operating Principles: |
Supply Air Stream
Outside air is drawn into the unit using the supply fan.
The warm, moist outside air first passes through filters and then the cooling coil where it is cooled.
The air then goes through the desiccant wheel where the air is dehumidified and the temperature is raised.
At last the air is delivered directly to the space or into an existing air handler.
Exhaust Air Stream
Exhaust air is used to provide energy recovery for the desiccant wheel and is drawn into the unit using the exhaust fan.
The air filtered and then heated and humidified during the energy recovery process.
The air is then heated while passing through the regeneration coil.
The heated air removes the moisture that the desiccant wheel adsorbs from the process air stream.
| Our Advantages: |
- High dehumidifying capacity
- Dry air with super ow humidity can be easily obtained
- It is able to supply dry air with super low dew point less than -70 Celsius degree.
- Its dehumidification performance is more marked under the environment of low temperature and low humidity.
- Easy to operate and management, low operating cost
- Long ife and durable
- Complete equipment model, perfect dehumidification function
- Environment protection, pollution-free
| Human-machine Interface: |
| Refrigeration System for Option: |
| Application: |
| Certificates: |
