Taijia digital crack monitoring / crack integrated detector / Concrete cracks meter Concrete Detector

Product Description

Product Description
digital crack monitoring / crack integrated detector / Concrete cracks meter BJQF-1 crack width gauge is mainly used for the accurate detection of bridges, tunnels, buildings, concrete pavement, metal surface and so on. The system can automatically capture the image of cracks and real-time display crack images and their width data.The image data can be saved automatically. 1. Smart detection mode, crack position without adjustment2. Scale testing method, it is convenient to detect the same crack several times and compare the testing data3. Standard probe and high grade probe;4. Save crack images quickly with the snapshot button;5. 4GB large-capacity SD card can store more than 100,000 data, powered by lithium batteries; ItemBJQF-1 crack width gaugeHardware PlatformEmbedded ARM9 Hardware PlatformOperating SystemWinCe5.0ScreenTrue Color TFT Touch ScreenRangeStandard Probe: 0.01mm~6.5mm;Accuracy Standard Probe≤±0.02mm;Image Storage FormatBMP or JPEGPower SupplyRechargeable Lithium BatteryWorking Time≥28 HoursOperating temperature-10°C~+50°CHumidity≤90%RHDimensions180mmx100mmx50mmNet weight1kg Company InformationDalian Taijia Technology Co.,Ltd is a high technology company which specializes in supplying and supporting of ultrasonic measurement equipment. prime products include ultrasonic transit-time flow meter, ultrasonic level meter, ultrasonic thickness meter etc. Our products are widely used in water supply and drainage water, petroleum and chemicals, food and pharmaceutical.We have sold product in more than 30 countries, such as America. Italy. India. Korea. Germany. Canada. Australia etc.We thank you for visiting our Web Site and look forward to the opportunity of being of service to you. Contact us
