China Advanced MDF (Medium Density Fiberboard) Production Line Manufacturer

Product Description

China MDF Making Machine Plant /Factory /Manufacturer
What is MDF board?
Medium Density Fiberboard (MDF), the full name of density fiberboard, is wood fiber or other plant fiber as raw materials, by fiber preparation, the application of synthetic resin, under the condition of heating and pressurizing, pressed into the board.
According to its density can be divided into high density fiberboard, medium density fiberboard and low density fiberboard. Among them, the nominal density of MDF fiberboard ranges from 650Kg/m³ to 800Kg/m³
The density board is widely used in domestic furniture, decoration, Musical Instruments and packaging because of its uniform structure, fine material, stable performance, impact resistance and easy processing.
Advantages:
1. Density board is easy to finish processing. All kinds of coatings and paints can be evenly coated on the density board, which is the preferred substrate for paint effect.
2. Density board is a beautiful decorative plate.
3. All kinds of wood veneer, printing paper, PVC, adhesive paper film, melamine impregnated paper and light metal sheet and other materials can be finished on the surface of the density board.
4. Hard density board punching, drilling, can also be made into sound absorption board, used in architectural decoration projects.
5. Excellent physical properties, uniform material, there is no dehydration problem.

MDF Board production line
How to produce MDF board? what machine are required?
The whole production line mainly includes: Chipping machine, Screen, Defibrator, Dryer, Forming machine, Pressing machine, Cooling. Sanding machine, Cutting machine.
Each machine can be different specification according to different production capacity and other factors.
Now i will introduce some mainly mdf board machine for you
Wood chipper

Vibrating screening, for screening big wood strands, suitable strands, and sawdust.
Rotary drum dryer, for drying wet strands/flakes
Mat forming machine, for spreading glue on wood strands, seperately spreading glue on surface strands and core strands
Continuous pre press machine for pressing particleboard and discharge its inside air
Automatic Multi-layer hot press machine, for pressing the particleboard be in required thickness and be solid and strong.
Auto cutting machine for trim wood based panel product
High accuracy sanding machine for make particleboard thickness accurate and surface smooth
<1> Drum Chipper

Inlet size	300*1050mm(H*W)
Blade quantity	2pcs
Knife roll diameter	1000mm
Infeeding speed	36.5m/min
Power	250kw

<2> Screening

Screening mesh	2
Screening area	15 m2
Screening capacity	250-380m3/h
Power	15kw
Weight	8000kg

<3> Gluing system

Paraffin metering system	Metering pump flow: 400 L/h Metering tank volume: Dia 100 L
Glue measuring system	Glue metering pump flow: 2000 L/h Glue measuring tank volume: 4000 L
Curing agent metering system	Curing agent tank: 400 L Curing agent melting tank: 200 L
Additives measuring system	Additive tank: 400 L Metering pump flow: 50 L/h Additive melting tank: 200 L
Glue spray head	Number of spray heads: 6

<4> Drum Dryer

Cpacity	10t/h
Original moisture	90%
End moisture	8-12%
Power	500kw

<5> Forming Machine

Capacity	15t/h
Forming width	1450mm
Forming thickness	200-600mm
Forming belt speed	5-20m/min

<6> Continuous pre press machine

Convey speed	6-26m/min
Belt width	1750mm
Power	75kw
Number of holding rolls	10

<7> Slab edge cutting machine

Slab width	1250-1350mm
Saw blade diameter	710mm
Crosswide edge cutting machine
Saw blade move speed	12-30m/min
Saw blade diameter	500mm

<8> Hot press

Pressure	1500 ton
Oil cylinder	Dia 450mm *4pcs
Hot plate size	2750*1680*110mm
Layers	22
Heating medium	Oil
Heating temperature	≤180ºC
Closing time	20s

<9> Sanding machine-2 sanding heads

Max sanding width	1300mm
Sanding thickness	3-50mm
Sanding belt size	1350*2800mm
max infeeding speed	90m/min
Mainly motor	2*90kw
Thickness error	±0.05mm

Please note: each machine can be different specification according to different production capacity, panel size and other factors.

Company Profile
We China manufacturer and supplier of Particle board making machine+ MDF board making machine +OSB board making machine. if you want to produce these board, we can offer you the full necessary production line.
With many years production experience, and adhere to continuous innovation and improvement, with specialized R&D center, obtained a number of research and development patents, with experienced technians and engineers, and professional sales team and after-sales team, We have beome one China's high-end Wood based panel machinery manufacturing enterprise.
According to your own conditions like the budget, factory room and other factors, we can offer you the suitable, good and high quality machine for help you produce good quality panel.
For us, we know clearly that only keep machine good quality, can let us develop longer and better. Therefore, we always keep to choose good material and parts to make our machine, and during the whole machine production process, be made by experienced workers, and through many times test and monitor, to make sure each production step is good, to make sure the whole machine is good.

Packaging & Shipping

FAQ
<1> Machine Installation:
We can send engineers go to install machine, degue, and teach your workers
<2> Warranty:
15 months
<3> Production time:
3 months
<4> Payment terms:
T/T or L/C
<5> Factory layout:
After machine production start, we can make factory layout for you
<6> If meet problem when operation machine
Contact us at the first time, our engineers will help check and solve quickly

Welcome contact us for more information if you are interested, we will reply you quickly
