5tons Per Batch Ventilating Grain Dryer

Product Description

Ventilating grain dryer
Bed type dryers come in two configurations: one-way ventilate and double-way ventilate. In the one-way ventilate structure, the airflow moves across material layers from bottom to top. On the other hand, the double-way ventilate structure enables the airflow to traverse the material layers in two directions, ensuring uniform drying throughout. This dryer is effective in drying a variety of grains and seeds, minimizing the rate of breakage.

Model	TW5HD
Heating way	Indirect heating
Structure	Flat bed type
Capacity	5ton
Drying speed	0.5~1.0%/H
Drying capacity	≥13.5t·%/h
Hot air temperature	35~70ºC
Induced draft blower	0.55kw
Moisture exhaust blower	2x3kw
Total power	6.55kw
NW-kg/set	1100kgs
External size of the box	6090x2490x1150mm
Heating method	Wooden,coal,husk
Rated consumption	5-10kg/h

HUNAN TOWIN MACHINERY CO.,LTD founded in 1993,It is the best professional company in design, manufacture and sale of grain processing machine.
After 25 years of development, the company has trained a group of high calibre managers and a one-stop service team with a number of proficient, experienced technical backbone and R & D design people.The company has a group of professional technicians to provide 15-1000Ton per day rice processing engineering design for users, and has a group of experienced installation team to provide high-quality and efficient equipment installation, and after-sales service for users.
The company is renowned for its reliable product quality, mechanical stability and considerate technology service. Its products sell well all over the country, and are exported to Southeast Asia, South America, Africa and other countries and regions.
