TN-VA LCD Panel with Pin Connetor Sick Screen Print (8D0013)

Product Description

Product Description Graphical LCD 128*64 Specifications:
Module Size: 78(W)*37.40(H)*5.30(T) mm
View Area: 53.4(W)*25.2(H) mm Display mode: Positive, Transmissive
Driving IC: ST7567
IC bonding: COG
DOT matrix: 128x64
Connector: FPC
Display type: STN
View direction: 6 o'clock Mechanical Data

NO	ITEM	SPECIFICATION	UNIT
1	Dot Marrix	128(W) x 64(H)	dot
2	Module Size	78.00(W)*37.40(H)*5.30(T)	mm
3	View Area	53.4(W)*25.2(H)	mm
4	Active Area	46.05(W)*22.05(H)	mm
5	Dot Size	0.33(W) x 0.315(H)	mm
6	Module Thickness	5.30	mm

Spec:
SIZE:length*width*highth
DISPLAY TYPE: VA TN DISPLAY
LCD OPERATIONG VOLTAGE :5.0v?(3V-5V.>2.8V IS OK)
OPERATING TEMP:-20-70C
STORGER TEMP:-30-80C
DRIVE MODE: 1/4DUTY ,1/3BIAS
VIEWING DIRECTION: 6H(BOTTOM VIEWING)---(12H,6H,3H,9H)
POLARIZER TYPE: FRONT :TRANSMISSIVE,
BACK: TRANSMISSIVE
CONNECTOR: PIN (20)
BACKLIHGT: WHITE WITH TWO LIGHT,/BLUE BL (CUSTOMER DESIGN)
