Road Cold Milling Machine 2m Wide Wheel Milling Machine Xm200e

Product Description

Road Cold Milling Machine 2M Wide Wheel Milling Machine XM200E
XM200E asphalt concrete milling machine is the maintenance construction machinery of asphalt concrete pavement, mainly used for excavation and renovation of highway, urban road, airport, freight yard, parking lot and other large area of asphalt concrete pavement. The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation. Performance and characteristic:
1.Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.
2.Compact three-wheeled machine with front-wheel drive. 3.The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.
4.The imported hydraulic elements have high working reliability. 5.Hydraulic handheld breakers and rumble strip equipment can be selected.

Model	Unit		XM200E
	Max. milling with	mm	2000
	Max. milling depth	mm	300
Milling wheel	Number of tools		162
	Drum diameter with tools	mm	980
Engine	Model		DHP12
	Rated power	kW	353
	Rated speed	rpm	2100
Specifications	Operating speed	m/min	0~34
	Travel speed	km/h	0~5
	Ground clearance	%	80
	Ground clearance	mm	≤320
	Operating weight	kg	28500
Volume	Fuel tank	L	800
	Hydraulic oil tank	L	300
	Water tank	L	2300
Conveyor	Width	mm	800
Measurement	Overall machinery LxWxH	mm	6750×2500×2900
	Conveyor LxWxH	mm	8000×1150×900
Travel mode			Track
