Road Cold Milling Machine 2m Wide Wheel Milling Machine Xm200e

Road Cold Milling Machine 2m Wide Wheel Milling Machine Xm200e

US$150,000.00
1-4 Set
US$100,000.00
5+ Set

Basic Info.

Model NO.
XM200E
Type
Tool Milling Machine
Object
Tool
Structure
Flat
Milling Cutter Type
Angle Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Semiautomatic
Precision
High Precision
Certification
CE
Condition
New
Product Name
Cold Milling Machine
Model No
Xm200e
Transport Package
Nude Package
Specification
8165*3016*3485mm
Trademark
Evangel
Origin
China
Production Capacity
100 Sets/Month

Product Description


Road Cold Milling Machine 2M Wide Wheel Milling Machine XM200E
XM200E asphalt concrete milling machine is the maintenance construction machinery of asphalt concrete pavement, mainly used for excavation and renovation of highway, urban road, airport, freight yard, parking lot and other large area of asphalt concrete pavement. The equipment features advanced performance, high efficiency, simple process, easy control of milling depth, flexible operation, good maneuverability and the old material recycling and utilization. It is an ideal equipment for pavement maintenance and renovation. Performance and characteristic:
1.Hydraulic driving milling drum has the obvious characteristics of stable milling and high efficiency.
2.Compact three-wheeled machine with front-wheel drive. 3.The high-strength and high wear resistance imported cutter head and cutter rest have long service life and low construction cost.
4.The imported hydraulic elements have high working reliability. 5.Hydraulic handheld breakers and rumble strip equipment can be selected.
Model
Unit
XM200E

Max. milling with
mm
2000

Max. milling depth
mm
300
Milling wheel
Number of tools

162
Drum diameter with tools
mm
980
Engine
Model

DHP12
Rated power
kW
353
Rated speed
rpm
2100
Specifications
Operating speed
m/min
0~34
Travel speed
km/h
0~5
Ground clearance
%
80
Ground clearance
mm
≤320
Operating weight
kg
28500
Volume
Fuel tank
L
800
Hydraulic oil tank
L
300
Water tank
L
2300
Conveyor
Width
mm
800
Measurement
Overall machinery LxWxH
mm
6750×2500×2900
Conveyor LxWxH
mm
8000×1150×900
Travel mode

Track
