Low Speed Adult Diaper Machine (JWC-LKC)
| US$1,200,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JWC-LKC
Production Speed
＜150pcs/min
Computer Control Panel
Yes
Product Specification
Adult Diaper Machine
Automatic Grade
Automatic
Certification
CE, ISO
Condition
New
Process
Finishing Process Machine
Usage
Household Paper Machine
Type
Laminating Machine
Transport Package
Wooden Box for Diaper Machine
Specification
ISO9001, CE
Trademark
JWC adult diaper machine
Origin
China
HS Code
84413030
Production Capacity
30 Set/Year
Product Description
Low Speed Adult Diaper Machine (JWC-LKC)Product Description
This I shape Adult Diaper Machine includes main machine, glue applicators, packing system and other accessory equipment including air compressor, vision detection system and metal detection machine etc. This I sahpe Adult Diaper Machine can produce 3-5 sizes diapers according to the order. This production line can realize 100% full automatic control.
| 1.Double route forming system with wrapping by tissue, using large and small cotton cores. The products are economic and practical. SAP may be supplied at a fixed amount in designed locations or in a mixing way. 2.Crusher system adopts sawmill or hammer mill with long fiber and better absorbent capacity. 3. Fluff core uses double-moulds forming or aggregate unit. 4. With warning function for SAP in lower place. 5. With standing cuffs, frontal waist tape, sides waist tape, elastic waist tape, elastic rubber for leg mechanism. | 6. Main material with constant tension control auto-unwinding, rectifying a deviation guide. (option device) 7. Tri-folded arranging out. 8.With warning and shutting down functions by PLC control, material end detection and rejection system. 9. Driven by frequency. Machine with PLC control and touchable screen. 10. Hot-melt applicator is set in front of the machine. Such bridge style makes it easy to feed the glue and control the temperature. (option device) |
| Model | JWC-LKC-SL |
| Designed speed | 140m/min |
| Practical speed | 80-120PCS/min |
| Machine size | ( 30× 6× 3)M(L× W× H) |
| Working space | ( 34× 8× 4)M(L× W× H) |
| Machine weight | 28.5T |
| Installed capacity | 150KW (380V 50Hz) Breaker Capacity: 400A |
| Practical capacity | 100KW (380V 50Hz) |
| Air compressor | 1.5 m3/min |
| Electric wire | 3x70 mm2+1x25 mm2+1x16 mm2 |
| Product size | S, M, L |
| Container | 2× 40HQ |
