Product Description

Tk-Pm300 Mini Handhold Fiber Optic Powermeter easy operating
Optical Power Meters are part of the toolbox essentials for all technicians installing or maintaining any type of fiber networks. There are general-purpose power meters, semi-automated ones, as well as power meters optimized for certain types of networks, such as FTTx or LAN/WAN architectures. It's a matter of choosing the right gear for the need.
TK-PM300 Handheld Optical Power Meter is a newly designed fiber optic tester, which aims at the installation, engineering acceptance and maintenance of fiber network.
Compared with other usual power meters, the TK-PM300 has more functions, like automatic wavelength identification, auto wavelength switching, intelligent backlight, data saving via USB port.
Combined with TK-LS300 handheld optical light source, it offers a quick and accurate testing solution on both SM and MM fibers.
Features
. Wave ID Auto wavelength identification & switching
. Frequency ID ---Auto frequency identification
. 2 types of backlight modes, manual or outside light intensity, which indicated by LED light red or blue color.
. Intelligent backlight
. 1000 records storage or download via USB cable
. USB communication port for saved testing records download
. Reference power level can be set up and stored
. User self-calibrating function
. Auto-off function
. Up to 240hrs batteTK life

Specifications

Model	TK-PM300A	TK-PM300C
Calibration Wavelength(nm)	800~1700
Detector type	InGaAs
Measurement Range(dBm)	-70+10	-50+26
Uncertainty (dB)	+0.2(5%)
linearity (dB)	0.01
Display resolution(dB)	0.03
Frequency ID Hz	270 330 1K 2K
Wave ID nm	850,980,1300,1310,1490,1550,1625
Date Storage Capacity	1000
Communication Port	USB
Connector	FC/SC/ST Interchangeable
Alkaline batteTK	3AAA 1.5V or Li batteTK (9V)
Power Adapter(V)	8.4
BatteTK Operating time (h)	240 without backlight
Operation Temperature(oC)	-10(oC) +60
Storage Temperature(oC)	-25(oC)+70
Dimension(mm)	172*82*33
Weight(g)	310

Packages

MODEL	INCLUDES
All TK-PM300 Models	TK-PM300 Optical Power Meter, 3pcs 1.5V Batteries, Power Adapter, User Manual, USB cable, CD, Cotton Stick and Soft CarTKing Case.
