Cosmetics Mineral Water Supplement Spray Can Machine Product Line

Product Description

A.Product Details
Applicable Industries:Manufacturing Plant
After Warranty Service:Video technical support, Online support
Local Service Location:Viet Nam, Indonesia, Pakistan
Showroom Location:Viet Nam, Indonesia, Pakistan, Tajikistan
Application:Food, Beverage, MEDICAL, Chemical
Automatic Grade:Automatic
Driven Type:Electric
Voltage:380V/50Hz
Dimension(L*W*H):69m*4.5m*6.3m
Weight:90000KG
Certification:CE Certification
Warranty:1 YEAR
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Key Selling Points:High Productivity
Production Speed:80-120pcs/min
B.Packaging & Delivery
Selling Units:Single item
Single package size: 50X50X50 cm
Single gross weight:50.000 kg
Package Type:International Export Standard Wooden Case

Packaging Imformation
Size	69 (L) * 4.5 (W) * 6.3 (D)m
Weight	90T
Packaging Details	International Export Standard Wooden Case

C.Product Application
Aluminum can line are a set of machines to produce mono block aerosol cans and bottles.
Mono block cans and bottles are used for perfume, deodorant, hair sprays, shaving creams, pesticide bottles, aluminum tubes, hair sprays, conditioners, medicines, fire extinguishers, oil and paints.
The XR series aluminum can lines produced by us are fully automatic. Each equipment of this series can work alone or form partial production lines according to client's needs. The main machines include YR01 Extrusion press, XR02 Trimmer cum brushing, XR03 can washer or degreasing Spray washing machine,XR04 Accumulator, XR05 Internal lacquering machine, XR06 Lacquer curing oven, XR08 Base-coating machine, XR09 6-color or 8-color printing machine, XR12 Drying oven, XR14 and XR14E Necking machine, etc.
All the equipment of the series are properly aligned in structure, having advance design, highly automated for fast production. All machines are controlled with SIEMENS PLC to ensure stability. To save energy consumption, all lacquer curing machine and drying oven adopt gas heating. Main units and controlling components all adopt branded products to ensure reliable and stable performance. All the products can be passed automatically through the production line. The color touch screen can display the instant information of speed and production, making it convenient for management.
creen can display the instant information of speed and production, making it convenient for management.

SPECIFICATIONS FOR AlUMINUM AEROSOL CAN PRODUCTION LINE
Production speed		≤120pieces/min
Diameter		φ22mm- φ35mm,φ35mm-φ53mm or φ45mm- φ66mm
Motor power		230KW
Dimensions		69000×4500×6300(mm)
Intake pressure		0.55 MPA
Gas consumption		500M^3/24h

D.Main Machine
Machine flow chart:Extrusion-Trimming-Washing-internal lacquering-Base Coating-Printing-Vanish-Necking Name: XR01 Extrusion press machine Main technical parameters
A. Can diameter range: φ35mm-φ59mm
B. Can length range: 80-250mm
C. Production speed: ≤120cans/min
D. Main motor power: 37KW, Total power:37.28KW
E. Intake pressure: ≥0.4Mpa
F. Slide stroke:350mm
G. Net weight: 11000 KG
H. Dimensions: 3195*1558*1585mm(conveyer belt and vibration hopper not included)

Name: XR09 6-color Printing Machine
Main technical parameters
A. Can diameter range: φ35mm-φ66mm
B. Can length range: ≤230mm
C. Production speed: ≤120cans/min
D. Motor power: 19.17KW
E. Dimensions: 3340×2330×2100mm
F. Net weight: 7600KG
G. Intake pressure: 0.6Mpa
E.Main Configuration List
1) PLC: SIEMENS
2) Touch screen: Pro-face
3) Pneumatic element:FESTO
4) Terminal display:SIEMENS
5) Bearing:NSK or NTN
6) Approach switch:BANNER
7) Photo switch:TURCK
8) Divider:TANTZU
9) Electrical component:SCHNEIDER or OMRON
