GS300A Cantilever Moving Type Surface Grinder Grinding Machine for Metal

Product Description

One-stop Shopping
Please click on the picture to view the product category you are interested in

Conventional Lathe	CNC Lathe	CNC Machining Center	CNC Milling Machine
Grinding Machine	Milling Machine	Special Use Lathe	Boring Machine

Product Description
surface grinder grinding machine
It is designed with cantilever moving type, reasonable structure and nice-looking.
It is surface grinding machine with grinding workpiece around ground wheel, and it can also grinding side surface of workpiece by grinding wheel side-face. The workpiece can be clamped by electromagnetic chuck, or fixed directly on the worktable, or other fixtures .
Wheelhead is equipped with a quick lifting mechanism, which can reduce labor intensity and improve work efficiency.
The distance between the oil recovery point and the oil entry point in the oil pool is the longest, and the hydraulic oil is circulated
to balance the oil temperature distribution and reduce the thermal deformation of the machine.
Beautiful shape, good rigidity, stable and reliable performance and easy to maintenance.
According to customer's need, can choose inverter driven on wheelhead cross movement, realize stepless speed adjustment.
Optional magnetic separator and paper filter to reduce the dust of the cutting liquid and ensure the grinding process.

SPECIFICATION	UNIT	GS-300A	GS-400A	GS-500A
Table width	mm	300	400	500
Table length	mm	1000	1000/1600/2000	1000/1600/2000
Max. grinding width	mm	300	400	500
Max. grinding length	mm	1100	1100/1700/2300	1100/1700/2300
Max. grinding height	mm	400	400	500
Distance from spindle to table	mm	600	600	700
Longitudinal feed speed	m/min	3-27	3-27	3-27
T-slot (No. /width)	mm	3/18	3/18	3/22
Cross continuous feed speed	m/min	0.5-4.5	0.5-4.5	0.5-4.5
Cross intermittent feed rate	mm/str	3-30	3-30	3-30
Cross feed of handwheel per gra.	mm/gra	-	0.02	0.02
Vertical rapid feed speed	mm/min	400	400	400
Vertical feed of handwheel per gra.	mm/gra	0.005	0.01	0.005
Vertical feed of handwheel per rev.	mm/rev	0.645	0.645	0.515
Main motor power	kw	7.5	7.5	7.5
Spindle speed	rpm	1440	1440	1440
Total power	kw	11	11	12.25
Loading capacity(include chuck)	kg	470	630/1000/1380	700/1240/1410
Grinding wheel size	mm	400x40x127	400x40x127	400x40x203
Overall dimensions(LxWxH)	mm	2860x1540x2030	2880x1770x2030	3110x1900x2420
			4940x1820x2230	5140x1900x2420
			6740x1820x2230	6740x1900x2420
Machine weight	kg	3500	4700/6600/8000	5000/7100/8500

MAIN CONFIGURATION & ACCESSORIES: Grinding wheel, Wheel balancing arbor, Wheel extractor, Coolant system, Work lamp, Wheel flange, Wheel dresser, Leveling wedge and bolt, Tools and tool box, Operation manual (English edition).

OPTIONAL CONFIGURATION & ACCESSORIES: Diamond pen, Electrical magnetic chuck, Wheel balancing stand, Paper fliter, Magnetic separator, Demagnetize

Our Advantages
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period.
2. Quick action and reply for the technical questions at any time in the whole life of the machine.
3. Overseas after service center available in some region.
4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
