10~24m Diesel Electric Hydraulic Towable Boom Lift
| US$6,999.00-8,999.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
TBL
Application
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism
Hydraulic
Carrying Capacity
200 Kg
Moves
Towable
Driven Type
Hydraulic
Running Mode
Moving
Feature
Explosion-Proof, Insulating
Certification
GS, CE, RoHS, ISO 9001
Power Available
AC/DC/Diesel/Gasoline/AC+DC, etc
Color
Yellow, Red, Green, or Per Your Request
Maximum Platform Height
10m, 12m, 14m, 16m
Maximum Working Height
12m, 14m, 16m, 18m
Voltage
220V/110V/230V or Per Your Request
Type
Telescopic
Transport Package
Full Container
Specification
5500*2200*2200
Trademark
PLK
Origin
China
HS Code
8428909090
Production Capacity
500 Per Month
Product Description
Articulated Hydraulic Aerial Platform Telescopic Towable Boom Lift For SaleTowable boom lift platform height from 10m to 16m (working height from 12m to 18m). Load capacity 200kg. It can be towed easily from site to site and work for you quickly. It is widely used for aerial working, such as road lamp repair, palm tree trimming work and cleaning the window etc.
Power options available on PLK towable boom lift include AC (connect with electricity), DC (battery power), gasoline, diesel and 'Dual-Energy' ( for example battery & diesel or battery & gasoline), combining the benefits of two power sources on the same machine. Towable Cherry Picker is popular for its easily moving and operation. Having it will be your wisest choice.
| Model | TBL-12A | TBL-14A | TBL-14AT | TBL-16A | TBL-18A | TBL-20A | TBL-22A | TBL-24A | |
| +Telescopic | +Telescopic | +Telescopic | +Telescopic | +Telescopic | +Telescopic | ||||
| Lifting height | 10M | 12M | 12M | 14M | 16M | 18M | 20M | 22M | |
| Working height | 12M | 14M | 14M | 16M | 18M | 20M | 22M | 24M | |
| Load capacity | 300KG | 220KG | 300KG | 300KG | 220KG | 220KG | 220KG | 220KG | |
| Platfor msize | 1.2*0.8M | ||||||||
| Working radius | 5.5M | 6.5M | 7.8M | 8.5M | 10.5M | 11M | 11M | 11M | |
| Net Weight | 1950KG | 2100KG | 2150KG | 2150KG | 2350KG | 3800KG | 4500KG | 5000KG | |
| Overall Width (A) | 1.7M | 1.7M | 1.7M | 1.7M | 1.7M | 1.8M | 1.8M | 1.9M | |
| Stowed Height (B) | 2.1M | 2.1M | 2.1M | 2.1M | 2.2M | 2.25M | 2.25M | 2.25M | |
| Overall Length (C) | 6.3M | 7.3M | 5.8M | 6.65M | 6.8M | 7.6M | 6.9M | 6.9M | |
| Length After Folding Tractor (D) | 5.2M | 6.2M | 4.7M | 5.55M | 5.7M | 6.5M | 5.8M | 5.8M | |
| Wind Resistance Level | <=5 | ||||||||
| Rotation | 359 degree (USD350 for 360d egree) | 360 degree | |||||||
| 20'/40'Container Loading Quantity | 1set/3sets | 1set/3sets | 1set/3sets | 1set/3sets | 1set/3sets | 1set/2sets | 1set/2sets | 1set/2sets | |
