CNC Machine Lathe of Lathe Chuck 200mm

CNC Machine Lathe of Lathe Chuck 200mm

US$11,000.00
1-4 Pieces
US$10,000.00
5+ Pieces

Basic Info.

Model NO.
CLK6140D-2
Type
Horizontal Lathe
Processing Accessory
Chuck CNC Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Controlling Mode
CNC
Automatic Grade
Automatic
Setting Mode
Floor-type
Precision
High Precision
Certification
GS, CE, ISO 9001
Condition
New
Product Name
CNC Lathe Machine
CNC Machine Lathe of Lathe Chuck 200mm
400
Max. Swing Over Cross Slide
170(Standard)/Option:150( with T-Slot)
X/Z Axis Travel
220/550(1000mm:860)
Z Direction Guideway Span
320
Uased as
CNC Lathe
Spindle Bore
51(Standard Manual Chuck )
Spindle Speed Range
2 Shifts:80-400,400-2000
Tailstock Sleeve Dia.
55
Belong to
Lathe Machine
Electric Tools
4/6(Option)
Tools Size
25*25
Net Weight
1800(1900)
Transport Package
Plywwod
Specification
CLK6140D-2
Trademark
ALLWAY
Origin
China
HS Code
845811
Production Capacity
1000PCS/Year

Product Description

Cnc Machine Lathe of lathe chuck 200mm CLK6140D-2
1.Introduction and use:
Electromechanical integration with 2-shifts of high /low speed, once programming can automatically realize machining such like cylindrical,inner hole, thread, complex surface.Widely used in machinery, automobiles, motorcycles, oil pump, nozzle, chemical industry, instrument, medical and other parts of mechanical processing.
2. SPECIFICATION
CLK6140D/2 Items UNIT 750 1000
Max. swing over bed mm 400
Max. swing over cross slide mm 170(standard)/option:150( with T-slot)
End surface of standard chuck (doesn't contain claws) to enter of tailstock mm 680 1000
X/Z axis travel mm 220/550 220/860
Z direction guideway span mm 320
Spindle bore mm 51(standard manual chuck )
Code for spindle nose A2-6
Spindle nose tape No Morse 6
Spindle speed range rpm 2 shifts:80-400,400-2000
Tailstock sleeve dia. mm 55
Tailstock No MT4
Tailstock sleeve travel mm 150
Electric tools pcs 4/6(option)
Tools Size mm 25×25
Screw pitch mm X:4;Z:6
X, z rapid feeding m/min X:6; Z:8
X/z axis smallest unit set mm 0.001
Main motor KW 5.5KW
cool pump AB-25
Cool pump motor w 90
Power form AC voltage V 3 380±10%
Frequency HZ 50±10%
Total Power capacity KVA 10
Net weight Kg 1800 1900
Overall dimension mm 2000×1100×1650 2320×1100×1650

3. Standard configuration:
1) Flat bed 750mm;
2) the surface contact with guideway of the longitudinal,cross slide carriage sticking PTFE.
3) Frequency conversion 2 shifts(manual change shift):80-400RPM,400-2000RPM;Triplex asynchronous motor: 5.5KW;
4) Spindle outer cycloid pump forced lubrication;;
5) Manual 3 jaw chuckφ200;φ200
6) 4 station electric tool post;
7) General tailstock;
8) lead screws/guideway auto oil lubrication;,
9) double door, half-full protection;
10) Stationary electronic handwheel;
11) Work light;
12) Ordinary cooling;
13) Manual iron plate;
14) GSK980TD CNC system.
4.Optional configuration:
1) FANUC,Siemens,Mitsubishi,HNC,GT66T,KND;
2) 1000mm Flat bed;
3) Manual 3 jaw chuckφ250;
4) hydraulic chuck / Rotary oil cylinder/ Hydraulic unit.
a) Entity φ200/φ250 hydraulic chuck from domestic or Taiwan.
b) through bar φ200/φ250 hydraulic chuck from domestic or Taiwan.
5) Entity φ200/φ250 pneumatic chuck and rotary pneumatic cylinder from domestic or Taiwan.
6) Hydraulic tailstock;
7) Pneumatic tailstock;
8) Cross slide with "T"-slot"T";
9) 6 station electric tool post;
10) Manul follow rest,steady rest;
11) manual lubrication.
12) full shield protection sheet
Contact ALLWAY MACHINERY , get more professional information!
