Intelligent 3D Busbar Processing/ Punching and Shearing Machine with Busbar Software
| US$1.00-10,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
EMAC-BP-40/60
Total Power
15.7kw
Processing Dimension
6000*200*15mm
Max Ounch Hole Size
32mm
High Pressure Electromagnetic Valve
Italy
Transport Package
Export Standard Free-Fumigation Wooden Case
Specification
Size: 7500*2980;
Trademark
BEIENE
Origin
Qingdao, China
Production Capacity
200 Set/Sets Per Month
Packaging & Delivery
Package Size
660.00cm * 218.00cm * 200.00cm
Package Gross Weight
6300.000kg
Product Description
Advantages
1. 3D software--This is our independent patent in busbar processing, which can realize 3D automatic programming and dynamic simulation.
2. Double clamps--Comparing other single clamp, double clamps can make processing more accurate and stable.
3. Hydraulic system-- Piston pump (rather than gear pump) has large drive power and realize high efficiency.
4. Main components--Imported, so the quality and service life can be guaranteed. Configuration
| Control Section | ||||||
| Serial No. | Name | Instruction | ||||
| 1 | Programmable Control | OMRON/Schneider | ||||
| 2 | Sensor | Schneider | ||||
| 3 | Control Button | OMRON | ||||
| 4 | Touch Screen | OMRON | ||||
| 5 | Computer | Lenovo | ||||
| 6 | AC Contactors | ABB | ||||
| 7 | Circuit Breaker | ABB | ||||
| 8 | Servo Motors | YASKAWA(Japan) or Schneider | ||||
| 9 | Servo Drivers | YASKAWA(Japan) or Schneider | ||||
| 10 | Control software and Three-dimensional computer-aided design | Gaoji Busbar Processing System(GJ3D) | ||||
| Transmission System | ||||||
| Serial No. | Name | Illustration | ||||
| 1 | Precision Linear Guide Rail | Taiwan HIWIN | ||||
| 2 | Precision Ball Screw Cylinder | Taiwan HIWIN | ||||
| 3 | Bearing | Japan NSK | ||||
| Hydraulic Section | ||||||
| Serial No. | Name | Illustration | ||||
| 1 | High Pressure Electromagnetic valve | Italy | ||||
| 2 | High Pressure Tube | Germany Rivaflex | ||||
| 3 | High Pressure Oil Piston Pump | Rexroth | ||||
Specification
| Description | Unit | EMAC-BP-40 | |
| Press Force | Punch Unit | KN | 400 |
| Shear Unit | KN | 400 | |
| X Max Speed | m/min | 100 | |
| X Max Stroke | mm | 1500 | |
| Y Max Speed | mm | 100 | |
| Z Max Speed | mm | 60 | |
| Minimum Oddment Length | mm | 55 | |
| Max Hit Speed | HPM | 150 | |
| Tool Kit | Punch Mold | set | 5 |
| Shear Mold | set | 1 | |
| Control Axis | 3 | ||
| Hole Pitch Accuracy | mm/m | ±0.20 | |
| Max Hole Punch Size | mm | 32 | |
| Max Busbar Size(W*H) | mm | 6000*150*12 | |
| Total power | kw | 15 | |
| Machine Size:L*W | mm | 6600*2180 | |
| Machine Weight | kg | 6300 | |
