High Cutting Speed Servo Wirecutting EDM Machine Hq-630GS
| US$18,888.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HQ-630GS
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
+-0.0025mm
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Driver
Servo Motor, Screw Error Compensation
Transport Package
Plywood
Specification
HQ40GZ-AS
Trademark
HANQI EDM
Origin
China
HS Code
84561090
Production Capacity
600 Sets
Product Description
The first domestic company puts the servo WEDM-MS into scale production, best choice for you to replace low-end stepper ones.
Widely used in mold manufacturing, profile, military academies and other industries.
The most widely used and favored product on the market. High quality casting, multiple tempering. "C" frame structure , "T" shape bed, ensuring the stability for a long time. U, V axes cross slide designed, compact structure.
| HQ-400GS | HQ-500GS | HQ-630GS | HQ-800GS | ||
| Machine | |||||
| Machine size | mm | 1680*1200*2300 | 1810*1350*2300 | 2100*1450*2400 | 2300*1600*2400 |
| Weight | kg | 2000 | 2500 | 3000 | 3800 |
| diameter of wire | mm | φ0.12-0.20 | φ0.12-0.20 | φ0.12-0.20 | φ0.12-0.20 |
| Power | kw | ≤2.3 | ≤2.8 | ≤3 | ≤3.5 |
| Workingtable Size | |||||
| Worktable travel(X/Y/Z) | mm | 400*320*300 | 500*400*300 | 630*500*300 | 800*630*300 |
| Worktable size | mm | 660*450 | 720*520 | 880*600 | 1050*650 |
| Working tank size | mm | 980*550 | 1180*710 | 1310*795 | 1400*940 |
| Maxworkpiece weight | kg | 400 | 500 | 700 | 800 |
| Generator | |||||
| Drive Mode | AC servo | AC servo | AC servo | AC servo | |
| Best Surface Roughness | um | Ra≤0.7 | Ra≤0.7 | Ra≤0.8 | Ra≤0.8 |
| Max cutting height | mm | 300 | 300 | 300 | 300 |
| Max Taper | °/mm | ±6°/80 | ±6°/80 | ±6°/80 | ±6°/80 |
| Max Machine Speed | mm²/min | ≥220 | ≥220 | ≥220 | ≥220 |
| Wire speed | frequency | frequency | frequency | frequency | |
| System | |||||
| Hardware | Fanl-free industrial computer,32G industrial SSD, Standard computer keyboard | ||||
| Communication | USB,LAN,RA232 | ||||
| Axis control | 4 axis simultaneous, lifting of guide wire is controlled. | ||||
| Language | Chinese, English, Russian, Japanese | ||||
| Power Supply | 380v±10%,50/60Hz,2kVA | ||||
Wire Cut EDM Machine Key Parts List
| Linear guideway | HIWIN P3 grade linear guideway |
| Ball screw | HIWIN silver C3 grade precision ball screw |
| Wire drum | HIWIN P3 grade linear guideway |
| U, V axis taper device | HIWIN P3 grade linear guideway |
| Bearings | Germany NEY precision bearing |
| Computer | Special industrial computer |
| Display | Industrial Display |
| Electrolytic capacitors | Japan Ruby or King Kong |
| X, Y axis servo motor | Japan Panasonic AC servo motor |
| Wire guider | Special type diamond guider for wire |
| Filtration systems | Brass WEDM type water filter |
| Z-axis electric lift | Electric type |
| Guide wheel | Special thickness guide wheel |
| Multifunction fixture | Brass WEDM type fixture |
| High-strength body structure | T sharp machine bed |
| Wire constant tension device | 2 sets constant tension device |
| High frequency pulse power | Japan technology, high speed, low roughness |
| Electrical | Schneider |
