Factory Supply FTTH Fiber Optic Modems F663 F663nv3a 1ge+3fe LAN Port + 2.4G WiFi Gpon ONU Ont with English Vision

Product Description

Product Description
F663NV3a FTTH is a single-frequency and economical smart gateway specially built. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem.
Feature: 1.highly reliable heat dissipation design guarantees its stable operation.
2.dual image ensures uninterrupted services during software downloading or upgrading, thereby enhancing software reliability
3.highly reliable lightning protection design provides lightning and surge protection of 4 kV for the adapter, 1.5 kV for the Phone interfaces, and 1.5 kV for the Ethernet ports.
4. full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation, administration and maintenance (OMCI/TR-069) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator's network. Product Parameters

Model	F663NV3a
Fiber interface	SC/UPC
Fiber port	1 GPON interface, 1GE+3FE LAN port + 2.4G WIFI,SC single-mode,
	Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength	Tx 1310nm, Rx 1490nm
Voice protocol	SIP, H.248
RX sensitivity	<-27dBm (1490nm)
WLAN	IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna
Net weight	≤0.6Kg
Configuration method	NMS, Web, or TR069
Power	≤8W
DC power	Adapter input: 100-240 V AC, 50 - 60 Hz ;
	Adapter output: 11 - 14 V DC, 1 A
Button	Reset, power
Operation	Working temperature: -0-+40ºC
	working humidity:5-95%(non-condensation)
Dimension	250*220*65mm(length*width*height)
L2 forwarding capability	Forwarding packets of any length at wire speed
IPv4 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
	1Gbit/s with any length packets in upstream direction
IPv6 L3 forwarding capability	2Gbit/s with any length packets in downstream direction
	1Gbit/s with any length packets in upstream direction
LAN	1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
