High Power Winding Machine for Powerful Coil Winding Technology Solutions.

Product Description

Introducing the Electric Winding Machine (DLM-0866), a remarkable feat of engineering brilliance, meticulously engineered to elevate your winding processes to extraordinary levels of efficiency and precision. This machine sets a new industry benchmark, offering unparalleled innovation and craftsmanship.
Presenting the DLM-0866 Coil Winding Machine, a pinnacle of precision engineering, expertly designed to deliver exceptional efficiency and outstanding performance for every coil winding application. Experience the epitome of innovation in every task.
1. Advanced Array Motor: Discover the dynamic and extraordinary high-performance capabilities of our cutting-edge array motor. It sets a new standard in winding technology, offering unmatched agility, precision, and reliability.
2. Automatic Computer Control: Seamlessly automate your processes with our sophisticated computer control system, designed for intuitive operation and unmatched ease of use, ensuring smooth, efficient, and precise workflow management.
3. Super Quality: Embrace unmatched excellence in design and functionality, with every aspect of the machine crafted to meet the highest standards of quality and performance, ensuring superior results in every operation.
Introducing the DLM-0866 Large Winding Machine, where impressive size meets impeccable functionality. This machine seamlessly redefines industry standards with its outstanding capabilities and robust performance.
1. This horizontal and automatic winding machine ingeniously integrates serial parallel coil formers, making it ideal for a wide variety of AC and DC motor stator coils, as well as inductance coils, vastly expanding its application possibilities.
2. Powered by a single board computer, this machine manages intricate tasks such as zero resetting, traversing, and skipping with precision, ensuring smooth alignment and exceptional operational accuracy.
3. User-Friendly Control Panel: Effortlessly customize your settings with precision by adjusting wire diameter, number of turns, traverse, and skipping distances to perfectly meet your specific operational requirements.
Technical Parameter: Explore the superior specifications that define our machine's exceptional capabilities, consistently delivering top-tier performance and unwavering reliability.
Suitable Wire Diameter: Expertly crafted to handle wire diameters from 0.1 to 1.2 mm with ease, ensuring versatility, precision, and effortless operation.
Winding Width: Offers an adaptable winding width from 0 to 30 mm, expertly catering to a broad range of applications with exceptional precision and adaptability.
Winding Diameter: Accommodates winding diameters between 25 to 180 mm, providing unparalleled flexibility and adaptability in operations, perfectly meeting diverse requirements.
Effective Length of Series-mode Axis: Features an expansive range of 500 to 600 mm, offering enhanced performance, capability, and operational flexibility.
Return Diameter of Former: Supports return diameters spanning 210 to 280 mm, optimizing efficiency, accuracy, and overall operational effectiveness.
Rotation Speed: Accelerate your operations with a dynamic rotation speed of 3200 R.P.M, significantly enhancing productivity and operational efficiency.
Power Source: Utilizes a dependable 220V 50Hz power source, providing consistent, reliable, and stable operation, ensuring maximum efficiency every time.
Pressure of Air Supply: Functions effortlessly within an air supply pressure range of 0.5-0.8 MPa, guaranteeing optimal performance, precision, and efficiency.
Power: Leverage the robust and reliable power of 750W to execute tasks with unmatched precision, dependability, and efficiency.
Dimension (L x M x H): A compact yet efficient design with dimensions of 1450 x 912 x 1200 mm, perfectly suited for various industrial settings, maximizing space and operational efficiency.
Weight: With a weight of approximately 800 kg, this machine offers a robust yet manageable solution tailored for diverse industrial environments, ensuring stability, durability, and unmatched performance.
