Pet PP PS PLA Cornstarch+PP Plastic Thermoforming Decorative Sheet Extruder Machine

Product Description

PET PP PS twin screw SHEET EXTRUSION LINE


Description:
1. PET Sheet Extrusion Machine is a combination of Raw material handling system, Extruder, Special Vacuum system,Special Screen Changer, melt pump, T-die, Three roll calender, temperature controller, Edge trimming unit, Edge trimming winder, Silicone coating & dryer, Haul-off, Winder, electric control cabinet and spare parts.
2. Screw and barrel adopt 38CrNiMoA,♦Special design of PET parallel twin-screw extruder; no need crystallize & dehumidify-dryer; ♦Elements screw design meets more material applications; ♦Four vents of barrel match the European technology vaccum system; ♦Universal Extruder design for 100% PET flakes or mixture of virgin + flakes, also available for running PP HIPS, PLA;♦Higher torgue gearbox, more capacity.
3. Good plasticizing, fast cooling, high output and stability, full automatic controlled by PLC.
4. This machine is suitable for mono-layer or multi-layer PET, PP, HIPS, PLA plastic sheet. It's widely used in the fields of plastic thermoforming products: fruit & vegetable containers, food/ cake boxes, egg trays, seedling trays, electric trays, stationery folders, decorative sheet, medical sheet, cups...
5. It adopts EU standard design. Siemens parts: motor, inverter, HIM, PLC control, buttons, air breaker; JCtimes: melt pump, T-die; GNORD: gearbox; NSK: roll bearing.
CONFIGURAION OF WHOLE LINE as follow:
Layout:
Details of main parts:

"CIE" PET sheet extruder
♦Special design of PET parallel twin-screw extruder; no need crystallize & dehumidify-dryer
♦Elements screw design meets more material applications.
♦Four vents of barrel match the European technology vaccum system ♦Universal Extruder design for 100% PET flakes or mixture of virgin + flakes, also available for running PP HIPS, PLA.
♦Higher torgue gearbox, more capacity.
CIE - "L" shape three-roll calender
♦Special design of PET sheet production processes, fastest cooling, highest accuracy
♦Standard of rolls stand is L shape, sheet surface can be touched as much as possible for higher transparency
♦Rolls stand can also be designed as inclined, horizontal, etc. based on requirements
♦Rolls driven & controlled individually, also synchronized
Electric control system
PLC (S7-1500, Siemens) screen: monitors all the temperature, speed, current and load rate of the whole production line. It has data processing function on screen: temperature, speed and pressure have trend curve for inquiry; alarm information display, as well as detailed historical alarm records, storage and transfer of process formula data.
General as follows:

	Raw Material:	APET/PETG/RPET/PLA/PP/HIPS, 100% recycle flakes
	Sheet thickness:	0.08mm-1.5mm, APET can be max. 2.3mm
	Net width of sheet:	600mm-1500 mm
	layer structure of sheet:	1-layer, 2-layer, 3-layer
	Extruding capacity:	400-500kg/h, 600-850 kg/h, 850-1000 kg/h, max.1700 kg/h
	Sheet application:	Thermoforming sheet, food box, fruit/egg trays, cups, electric trays, stationery, containers, medical sheet, etc.

PET rolls Application:
Company Profile:
CIE EXTRUFORMING MACHINE (SHANGHAI) CO., LTD. is a high-tech enterprise certified by the state. The factory is located in Fengjing Economic Development Zone, Jinshan District, Shanghai. For many years, it has been committed to becoming a leading supplier of plastic extrusion equipment and plastic thermoforming equipment in the industry. Since its establishment, the company has always followed the business philosophy of "integrity; pragmatism, development and innovation", and has long focused on the exploration and innovation in the design, R & D, manufacturing, sales and after-sales service of plastic extrusion equipment and plastic thermoforming equipment, aiming at providing customers with first-class overall solutions for the industry. CIE has introduced advanced technologies from Germany and Italy, and combined with its own multi-functional advantages Years of R & D and manufacturing experience and application cases, continuously manufacturing high-end, efficient environmental protection and energy-saving intelligent extrusion equipment for the industry. At present, it has been exported to many countries in the world and won high recognition and praise from customers in the industry.
We are different
CIE has the same elite R & D team, and its core members have more than 10 years of product R & D and design experience in related industries. They can provide customers with mature, stable and efficient overall solutions in the fields of plastic extrusion technology, plastic thermoforming technology, equipment and mold. Over the years, they have served many world-famous enterprises.
Excellent team
Over the years, CIE market operation team has been focusing on the promotion and application of plastic extrusion equipment and plastic thermoforming automation equipment It has the market development experience of world-class automation equipment manufacturing enterprises and the knowledge-how of many mainstream application industries. With its excellent ability and experience, we can more accurately grasp the market trend and meet the diversified needs of customers in the industry.
* We are a leading manufacturer with 12 years' experience * We have a complete and scientific quality management system
* Our quality can reach ISO and CE standard * We are loaded in Shanghai, which is convenient for exporting
Workshop:
Installation and maintenance:
Packaging and shipping:
Customers show:
We supplied to Thailand, Vietnam, India, Egypt, Indonesia, Russia,Poland, Turkey, Ukraine, Iran, Dubai, Spain, etc. Greece, Canada, Latin America, Saudi Arabia, Iraq, Congo, Ecuador will supply.
Turnkey project service:

1. we will provide all the machines for the complete production according to customer's requirements.
2. we will provide complete service for factory layout and other information to help customer to build the factory.
3. we can also provide the raw material to the customer if you need.
4. we will provide good service for machine installation and training, until the customers can run the machines and make stably production.
5. Except one year quality guarantee, we will provide after-sell service for all the life.
6. For long-term cooperation, we always provide good quality, good price and good service to customer. we are the professional and trustable supplier for turnkey projects. Let us do win-win business together.
