ISO Conveyor Roller/Idler Automatic Manufacturing Machine of Shaft Both Ends Flat Slot Milling Machine

Product Description

1.Product use and scope of application:
The product is a special automatic equipment for machining belt conveyor roller shaft with flat groove at both ends. It is suitable for production and processing of roller shaft at home and abroad.This machine uses the domestic advanced superposition valve hydraulic system, realizes the spindle box fast advance, fast back, and can speed speed stepless, the auxiliary man-hour is small, the work efficiency is high, can process the shaft head to pass the flat and the shaft head does not have the groove flat, Two ends of four processing surfaces at the same time.
It takes the imported programmable controller from Taiwan as the core, uses advanced contactless switch as the limit, carries on the program control. The work is stable and reliable, the degree of automation is high, and it is suitable for batch processing of the roller shaft. Is the conveyor industry shaft flat processing necessary equipment.Includes manual, automatic, and customer customization support
2.Technical parameter

project	parameter
model	TX-2023
Spindle rotation number	150r/min
Workpiece center height	850mm
Machining roller shaft diameter	Ф20-Ф40mm
Machining roller shaft length	260-2300mm
Machining shaft groove flat width	6-35mm
milling depth	0-5mm
Spindle motor	3kw×2
Working pressure of hydraulic system	1.5-4Mpa
Machine weight	3000kg
outline dimension	4000×1500×1440mm

Introduction of Cangzhou Terok International Trade Co., Ltd
Cangzhou Terok International Trade Co., Ltd. is a comprehensive enterprise integrating international trade, production, and sales. We are committed to providing high-quality products and services to global customers, and we also specialize in the production and sales of roller bearing housings, steel pipes, roller bearings, seals, and roller machine tools. The company boasts an experienced team adept at handling various international trade matters, including but not limited to import and export business, market development, and supply chain management. Additionally, our production team possesses profound professional knowledge and technical expertise in the fields of roller accessories and roller machine tools, enabling us to provide customers with high-quality products and customized solutions.
With our profound understanding of the market and strong resource integration capabilities, Cangzhou Terok International Trade Co., Ltd. has earned a solid reputation in the industry. We continuously strive for excellence and are committed to growing together with our partners to achieve mutual success. Whether it's international trade or the production and sales of roller accessories and roller equipment, we will repay every customer's trust and support with our professional attitude and high-quality products.
The company boasts a professional R&D team that continuously explores and introduces production equipment for rollers that reduce operational energy consumption and maintenance costs, such as semi-automatic machine tools for rollers, semi-automatic lines for roller processing, and fully automatic lines for roller processing. Simultaneously, the company creates greater value for its customers. The company primarily produces and sells rollers, stamped bearing housings for rollers (diameter φ60-φ219) in TD75 and DTII types, stamped center pillars, side pillars, H-frame tube housings, support plates, foot plates, waist drum rollers, seals, and various other mining conveyor components and stamped products.
In terms of sales and service, Cangzhou Terok is customer-oriented, providing personalized solutions and establishing a comprehensive pre-sale, in-sale, and after-sale service network to ensure that customers can enjoy timely and efficient support from anywhere in the world.
Cangzhou Terok International Trade Co., Ltd. has always adhered to the philosophy of "quality first, integrity in business". We have been dedicated to the field of international trade, working hand in hand with global partners to contribute to the development of the industry, and steadily striving towards becoming a top-tier international supplier.
