2000bph Small Water Bottling Blow Molding Machine

Product Description

Automatic 3 in 1 Bottled Water Filling Machine / Pure Water Filling Line
---This machine works for pure or mineral non carbonated water filling. It works in 3 steps, bottle rinsing, filling, and capping.
1) Conveying process: By adopting bottle-neck clamping design, or Hanging Type Bottle-Conveying System, the DCGF series can adapt many different shapes of bottles easily. It can be applied to your producing line directly with much less auxiliary units as well as inconveniences needed.
2) Filling process:
The DCGF series adopt Micro-Pressure technology which makes the filling process faster and more stable without losing pin-point filling accuracy.
3) Washing process:
Spring clamps are applied in the bottle washing unit. Empty bottles can be turned over by 180 degrees along the conveying rail. Two times of internal and external washing can guarantee the bottle washing quality.
4) Sealing process:
Magnetic torque technology is used for cap screwing. The force of cap screwing can be adjusted continuously without grade. This function guarantees a low defect rate of capping process.
5) Cap supplying process:
Air-powered horizontal swirl cap sorting device is applied in cap supplying process, in order to prevent cap from being scratched. And shortage of cap in Cap-Storing-Tank can be sensed out by sensors which can let out an alarming. After that, more caps can be reloaded automatically.
Flowchart:
Our options of water filling machine:

Model	RFC 8-8-3	RFC 10-10-3	RFC 18-18-6	RFC 24-24-8	RFC 32-32-10	RFC 40-40-12
Rinse nozzle	8	10	18	24	32	40
Fill nozzle	8	10	18	24	32	40
Cap nozzle	3	3	6	8	10	12
Output (@500ml, BPH)	2000	4000	6000	8000	10000	14000
Power(KW)	2	2.2	3.5	4.5	5.5	7.5
Applicable bottle	PET bottles with different shapes&volumes
Applicable bottle volume	100-2000ml(only if neck is same)
Applicable bottle height	160-320mm
Rinsing time	5-7''
Dimension (L*W*H, mm)	2000*1800*2300	2200*1800*2300	2500*2100*2400	2800*2200*2500	3500*2500*2900	4600*2800*2900
Weight(KGS)	2000	2200	3300	4200	4500	5000

Brand of main parts:

Item	Origin
PLC	Mitsubishi (Japan) , Siemens (Germany)
Touch screen	Weinview(Taiwan)
Frequency converter	Mitsubishi (Japan) , Siemens (Germany)
Air switch	Sch*eider (France)
Breaker	Siemens (Germany)
Contactor	Siemens (Germany)
Photoelectric switch	Omron (Japan)
Or other equal standard brand

More photos:
FAQ:
Q: Are you manufacturer?
-Yes, we have been in the line over 10 years.
Q: Where is your factory?
-Our factory is located in ZhangJiagang city, Jiangsu Province.
Q: How to visit your factory?
-Fly to Shanghai Pudong Air Port(PVG) or Wuxi, we'll pick you up there.
Q: WHat's your main product?
-We mainly produce beverage bottling/canning plant, like water, juice, or carbonated drinks.
As well as injection molding machine, molds, preforms, caps, labels, films, etc.
Q: Can I get a sample of your product?
-Sure, as you wish.
Q: What's the software you will use to check the drawing? And what's the format of drawing you can check?
-Our designers and engineers all use AUTO CAD to check 2D or 3D drawings.
-We can check the drawings with PDF, AI, DWG(CAD) and STP(3D) or IGS(3D) formats.
Q: How do you pack cargo?
-New seaworthy carton for preforms/caps/labels.
New durable wooden case for machines/molds.
