30HP Combined Rotary Screw Air Compressor with Receiver and Dryer

Product Description

Model	LGPM-10HP	LGPM-15HP	LGPM-20HP	LGPM-30HP	LGPM-50HP	LGPM-60HP
Motor Power(KW)	7.5	11	15	22	37	45
Capacity/Pressure (m3/min/MPa)	1.2/0.7	1.71/0.7	2.3/0.7	3.8/0.7	6.4/0.7	8.5/0.7
	1.1/0.8	1.65/0.8	2.25/0.8	3.6/0.8	6.2/0.8	8.0/0.8
	0.9/1.0	1.32/1.0	1.8/1.0	3.0/1.0	5.6/1.0	7.5/1.0
	0.8/1.2	1.1/1.2	1.6/1.2	2.6/1.2	5.0/1.2	7.0/1.2
LubricLGPMing oil(L)	12	16	16	22	26	26
Noise db(A)	60-70±2	60-70±2	60-70±2	60-70±2	60-70±2	60-70±2
Length(mm)	780	1050	1050	1300	1470	1460
Width(mm)	600	700	700	850	1000	1000
Height(mm)	1020	1150	1150	1100	1380	1380
Weight(Kg)	215	335	335	465	630	825
Model	LGPM-75HP	LGPM-100HP	LGPM-125HP	LGPM-150HP	LGPM-175HP	LGPM-200HP
Motor Power(KW)	55	75	90	110	132	160
Capacity/Pressure (m3/min/MPa)	10.5/0.7	13.2/0.7	16.2/0.7	21.0/0.7	24.6/0.7	31.0/0.7
	10.0/0.8	13.0/0.8	15.8/0.8	20.0/0.8	23.0/0.8	30.0/0.8
	8.5/1.0	10.9/1.0	14.0/1.0	18.0/1.0	21.0/1.0	26.0/1.0
	7.6/1.2	9.8/1.2	12.8/1.2	16.0/1.2	18.8/1.2	22.0/1.2
LubricLGPMing oil(L)	54	54	72	90	90	90
Noise db(A)	70-76±2	70-76±2	70-76±2	70-76±2	70-76±2	70-76±2
Length(mm)	1900	1900	1900	2020	2020	2360
Width(mm)	1250	1250	1250	1590	1590	1610
Height(mm)	1600	1600	1600	1810	1810	1860
Weight(Kg)	1130	1230	1325	1520	1710	185

Shandong Compressor Import & Export Co.,Ltd. is located in the logistics capital of China, one of the important
birthplaces of Chinese civilization-Linyi, Shandong Province.
With professinal manufacturing experience and first -class comprehensive scientific and technological strength of the talent team, as the energy-saving compressor system leader and remowed in the industry.
We specializes in R & D and sales of power frequency ,permanent magnet frequency conversion ,two -stage compressor permanent magnet frequency conversion ,low -voltage and mobile screw air compressor . With a deep industry background , one step ahead ambition .
With the professional enthusiasm for screw air compressor , team innovation , to meat the challenges of enterprise's
own determination and the rigorous attitude of excellence,products are strictly in accordance with IOS 9001 international quality procedures,to provide customers with energy -saving and reliable products .
We warmly welcomes people from all around the world to visit the company to guide the establishment of a wide range of business contacts and cooperation .
Choosing Shandong Compressor Import & Export Co.,Ltd.is to choose quality and service ,choose culture and taste ,choose a permanent and trustworthy partner ! RFQ:Q1: Are you factory or trade company?
A1: We are factory. Please check Our Company Profile.
Q2: What the exactly address of your factory?
A2: Mengshan Innovation Park, Zaoyuan Town, Linyi, Shandong, China
Q3: Warranty terms of your machine?
A3: 18 months warranty for the machine,technical support according to your needs.
Q4: Will you provide some spare parts of the machines?
A4: Yes.
Q5: How long will you take to arrange production?
A5: Deliver standard goods within 30days, Other customized goods is TBD.
Q6: Can you accept OEM orders?
A6: Yes, with professional design team, OEM orders are highly welcome.
