Durable High Power Winding Machine with Electric Coil Efficiency

Product Description

Introducing the Electric Winding Machine (DLM-0866), a brilliant feat of modern engineering innovation designed to elevate your winding processes to new heights of efficiency and precision. Experience the future of coil winding with a machine that sets the benchmark for excellence.
Presenting the DLM-0866 Coil Winding Machine, a true embodiment of precision engineering, meticulously crafted to deliver exceptional efficiency and superior performance in every coil winding task. Perfect your processes with technology that champions reliability.
1. Advanced Array Motor: Discover the high-performance marvel of our cutting-edge array motor, which sets a revolutionary standard in winding technology. Experience dynamic capabilities that offer unmatched power and efficiency.
2. Automatic Computer Control: Seamlessly automate your processes with our advanced computer control system, crafted for effortless and intuitive operation. Embrace the future of precision and convenience with a touch.
3. Super Quality: Embodying unmatched excellence, our machine is a pinnacle of design and functionality, ensuring the highest standards of quality across all aspects of performance. Elevate your operations with world-class engineering.
Introducing the DLM-0866 Large Winding Machine, a masterful fusion of size and impeccable functionality, poised to redefine industry standards and set new benchmarks in performance and reliability.
1. This horizontal and automatic winding machine is ingeniously equipped with serial parallel coil formers, perfectly suited for a diverse array of AC and DC motor stator coils, as well as inductance coils. Elevate your versatility and reach new operational heights.
2. At its core, the single board computer expertly manages complex tasks including zero resetting, traversing, and skipping, ensuring precise alignment and a seamless operational experience.
3. User-Friendly Control Panel: Effortlessly customize your operational settings by adjusting wire diameter, number of turns, traverse, and skipping distances, ensuring your specific needs are met with precision and ease.
Technical Parameter: Delve into the superior specifications that define our machine's extraordinary capabilities, consistently delivering top-tier performance and reliability.
Suitable Wire Diameter: Skillfully engineered to accommodate wire diameters ranging from 0.1 to 1.2 mm, ensuring versatility and user-friendly operation in every task.
Winding Width: Offers a versatile winding width from 0 to 30 mm, adeptly catering to a wide spectrum of applications with effortless adaptability.
Winding Diameter: Provides flexibility in operations with the ability to accommodate winding diameters between 25 to 180 mm, ensuring unparalleled operational versatility.
Effective Length of Series-mode Axis: Boasting an expansive range of 500 to 600 mm, this feature enhances performance and capability, delivering exceptional results consistently.
Return Diameter of Former: Supports return diameters spanning 210 to 280 mm, optimizing efficiency and enhancing operational effectiveness for superior outcomes.
Rotation Speed: Drive your productivity and efficiency with an impressive rotation speed of 3200 R.P.M, accelerating operations to new levels of performance.
Power Source: Operates on a dependable 220V 50Hz power source, ensuring consistent, reliable, and stable operation every time you switch on the machine.
Pressure of Air Supply: Maintains optimal performance and efficiency with an air supply pressure range of 0.5-0.8 MPa, delivering superior operational results.
Power: Unleash the robust power of 750W to execute tasks with remarkable precision and reliability. Experience unmatched performance and dependability in every operation.
Dimension (L x M x H): Streamlined and efficient with dimensions of 1450 x 912 x 1200 mm, this compact machine is perfectly suited for various industrial contexts, blending seamlessly into your workspace.
Weight: Approximately 800 kg, providing a solid and manageable solution for diverse industrial environments, ensuring robustness without compromising on portability or functionality.
