Trusted Suppliers Sinotech Made in China Toy Balls Injection Molding Machine with CE

Trusted Suppliers Sinotech Made in China Toy Balls Injection Molding Machine with CE

US$69,200.00
1 Piece
US$64,200.00
2 Pieces
US$59,200.00
3+ Pieces

Basic Info.

Model NO.
ST-500SElll
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE
Product Name
Injection Molding Machine
Function
Plastic Parts Production
Motor
Servo Energy Saving
Machinery Size
12.38m*2.8m*3.5m
Advantage
Energy Saving
Application
Plastic Products
Model No.
St-500selll
Machine Color
Blue+White
Transport Package
Woolen Case
Trademark
SINOTECH
Origin
Made in China
HS Code
8462299000
Production Capacity
1000/Year

Product Description

Trusted suppliers SINOTECH Made in China toy balls Injection Molding Machine with CE
Product Description
SINO-TECH ST-500SElll injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-500SElll with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features
1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3.Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 1600Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.
Product Parameters
Item Unit 500SElll
Screw diameter mm 70 80 94
Theoretical shot volume cc 1539 2011 2776
Shot weight (PS) g 1401 1830 2526
Shot weight (PS) oz 49.5 64.7 89.3
Length/Diameter ratio L/D 24.2 21.2 18
Injection pressure MPa 228 174 126
Injection rate cm³/sec 352 460 635
Injection stroke mm 400
Max. Screw speed rpm 170
Plasticizing capacity (PS) g/s 72.7 94.3 131.3
Injection unit force Ton 12
Carriage stroke mm 480
Clamping force Ton 500
Max. daylight mm 1700
Clamping stroke mm 850
Distance btwn. Tie bars mm 840*830
Min mould dimension mm 580*580
Mould thickness range mm 300-850
Ejector force Ton 16.6
Ejector stroke mm 240
No. of ejector pins unit 17
Max. motor power kW 50.7
System pressure MPa 17.5
Hydraulic pump capacity L/min 275
No. of heater zones unit 5+1
Heater input power kW 34.94
Ultimate capacity kw 86.64
Current A 118.5
Net weight Ton 18.66
Oil filling capacity L 700

Detailed Photos

Application
Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
