Basic Info.
Required Paper
Single PE Coated Paper or Double PE Coated Paper
Logo Printing
Without Logo Printing
Process
Finishing Process Machine
Usage
Packing Paper Machine
Type
Paper Folding Machine
Transport Package
Wooden Case
Production Capacity
60sets Per Month
Product Description
NAME: Paper Cup Machine
Model No.: YT-LI-70
YT-LI-70 Single PE Coated Paper cup machine is an automatic multi-working-station machine with Photosensor detecting, Failure alarming and counting. It's available for making oneside PE film coated paper cup against the procedure of automatic paper feeding, Sealing, silicon-oil lubricating, bottom punching, heating, knurling, curling and cup discharging. One-side PE paper cups are popular for tea, coffee, milk, ice cream etc. We have three different models of this machine
Model No. | YT-LI-70 |
Cup Size | 2-10oz |
Raw Material | one-side PE paper(140-200g/m2) |
Productivity | 60-75pcs/min |
Power Source | 380v/220v,50hz or others required |
Total Power | 4.5kw |
Weight | 1600kg |
Size(L*W*H) | 2130*1100*1600mm |
Packaging | PLYWood Case Packing |
Model No. | YT-LI-70 with Ultrasonic |
Cup Size | 2-10oz |
Raw Material | doubel PE paper(170-320g/m2) |
Productivity | 60-75pcs/min |
Power Source | 4.5kw |
Weight | 1600kg |
Size(L*W*H) | 2130*1100*1600mm |
Packaging | PYWood case |
