Jwell TPU High and Low Temperature Film/High Elastic Film Production Line, Transparent Breathable Composite for Footwear, Clothing, Luggage, Waterproof Zipper

Product Description

Product Description
JWELL-TPU High and Low Temperature Film / High Elastic Film Production Line
The production line adopts two or three extruders with inner co-extrusion design technology die head. Due to a specially designed thermal insulation die head, each layer temperature can be free and independent controllled. In order to reach the one step co-extrusion of different materials or different process temperature materials, meet the production of diversified combination products of various materials and solve the limitation that normal co-extrusion technology can not make such kind film at the same
time due to the large difference of material properties and temperature, the temperature of each layer can be controlled independently with this special design of thermal insulation die.

Performance and advantages
Versatility: Capable of producing multi-layer composite films with various combinations of materials and properties.
Precision Control: Advanced control systems for temperature, pressure, and film thickness ensure consistent quality.
Customization: Ability to produce films with different properties such as UV resistance, waterproofing, breathability, and high strength.
Efficiency: High-speed production with minimal downtime for maintenance and material changeovers.
Safety: Equipped with safety features to protect operators and maintain a safe working environment.
Application photos
TPU high and low temperature film, due to its soft, skin-friendly, high elasticity, three-dimensional sense, easy to use and other characteristics, is widely used in footwear, clothing, luggage, waterproof zipper and other textile fabrics, such as: sports footwear industry vamp, shoe tongue label, trademark and decorative accessories, luggage strap, reflective safety label, LOGO and so on.
Due to its excellent elasticity and bonding strength, TPU high elastic film is widely used in top-grade seamless underwear, seamless sportswear and other non-sutured fabrics.
Technical parameters

Technical parameters
Model	Products width(mm)	Products thickness(mm)	Capacity(kg/h)
JWS75/JWS120	1000-3000mm	0.02-2.0mm	300-350kg/h
JWS90/JWS90/JWS90	1000-3000mm	0.02-2.0mm	200-300kg/h
JWS65/JWS120/JWS65	1000-3000mm	0.02-2.0mm	300-400kg/h
Note: informations isted above are for reterence onlv, the production ine can be desianed ov customer's reauirements.

packaging&Shipping
In order to ensure the integrity of the goods in long-distance transportation, to avoid damage to the goods in sea transportation and corrosion of the sea water to the goods, to avoid damage in the process of freight transportation, we use the outer package-wooden box and the inner package-plastic wrap packaging to ensure the safety of the goods.If you have special needs, you can also tell us, we will do our best to do and let you rest assured
Company Profile
JWELL is a global supplier of complete solutions on extrusion technology.
Oriented from Shanghai, JWELL Mlachinery Co., Ltd is the largest manufacturer of extrusion machinery in China, its 8production bases are located in Jiading District of Shanghai, Zhoushan City of Zhejiang Province, Taicang city of jiangsuProvince, Liyang City of Jiangsu Province, Haining city of Zhejiang province,Chuzhou City of AnHui Province, Quaniao cityof AnhuiProvince and Thailand. Totally covering areas more than 1,000,000 square meters.t has more than 3000staffs, about 580 technicals and managing staffs with over 500 national patents, We produce more than 3000 advancedextrusion lines every year, which were exported to 120 countries and regions over the world.
Jiangsu Jwell Intelligent Machinery Co., Ltd. is a high-tech manufacturer dedicated to the research, development and manufacture of plastic extrusion equipment. Our main products are all kinds of plastic sheet, plate, film extrusion equipment. We not only have professional R&D team, experienced technicians, but also advanced production and processing base and standardized assembly workshop. Our customers are all over China as well as overseas countries and regions. Based on the enterprise spirit of "Excellent Quality, Perfect All", we are constantly exploring the new field of extrusion.
