Multi Discs Stone Cutting Machine for Marble Granite Into Slab (DQ2200/2500/2800)

Multi Discs Stone Cutting Machine for Marble Granite Into Slab (DQ2200/2500/2800)

US$28,600.00-33,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
DQ2200/2500/2800
Source Voltage
380V
Automation
Automatic
Cutting Ability
High Speed
Control
CNC
Certification
ISO, CE
Max. Cut Width
2200mm
Max. Cut Thick
230mm
Max Cut Size(L*W)
3200*2000
Table Tilting
0-85°
Table Rotation
360°
Payment
T/T,LC
Transport Package
Plastic Packing
Specification
max. cut length 3600mm
Trademark
AGA
Origin
China
HS Code
84641010
Production Capacity
300sets/Month

Product Description

Multi Discs Stone Cutting Machine
1.Product No.:DQ2200/2500/2800
2. Good services and warranty.
3. High power and easily operation.
Multi Discs Stone Cutting Machine Info:
A bridge type reliable and heavy duty machine with the latest technology for sawing stone block making slabs.The equipment is applicable for cutting granite, marble, sandstone, limestone, etc.It is able to carry multi blades when sawing granite stones that greatly raises the production output. The machine is microcomputer control and works by program automatically and also capable of manual operation.The heavy cast steel bridge provides excellent balance ensuring uniform thickness of each slab.
Multi Discs Stone Cutting Machine Specification:
Model
DQ2200A DQ2200B DQ2500 DQ2800
Max. blade size mm Φ2200 Φ2200 Φ2500 Φ2800
Max. cut length mm 2800 3600 3300 3200
Max. cut width mm 2200 2200 2200 2200
Max. cut depth mm 950 950 1100 1250
Spindle motor Kw 37/45 37/45 45 45
Total power Kw 44/52 44/52 52 52
Size (L×W×H) m 6.9×4.3×5.3 7.8×4.3×5.3 7.8×4.3×5.5 7.8×4.3×5.8
Weight Kg 11,000 11,500 12,000 12,300

Multi Discs Stone Cutting Machine Pictures:
Similar products as below show:
Pictures
Model DL2200 DL2500 DL3000
Max. blade size mm Φ2200 Φ2500 Φ3000
Max. cut length mm 3000 3000 3400
Max. cut width mm 2000 2000 2000
Max. cut depth mm 950 1100 1350
Spindle motor Kw 37 37 37
Water consumption cbm/h 6 6 6
Size (L×W×H) m 6.6×6.1×4.9 6.6×6.1×4.9 7.1×4.8×6.1
Weight Kg 9,000 9,500 12,000

Why AGA Company:
AGA has been devoting to making machinery for processing and fabrication of marble granite and providing reliable service. The products include bridge saw,block cutter,polishing machine as well as equipments for other construction stones.The equipments have been successfully exported to world stone market in U.S.A.,Canada, Europe, Mid East, Egypt, India,etc.
AGA understands that machinery creates value for customer and every machine comes from sophisticated technology and is manufactured by dedicated and experienced workers under strict inspection and full test. AGA insists on equipments of high quality and advanced technology to assist customers in their pursuit of a true competitive advantage. our philosophy is all about professional entrepreneurship and perfectly serving our clients and the mission is to help customers because by choosing us you are giving us a chance to make your machine more productive that also make your products unrivaled in the competitive market and we are happy to do that professionally and passionately.
AGA Products:
Stone cutting machine, multi blades block cutter, automatic bridge cutting machine, bridge saw, edge cutting machine, edge polishing machine, profile cutting machine, arm polisher machine, splitting machine, pressing machine, stone crusher.
Keyword:
Stone Block Cutting Machine,Stone Cutting Machine,Granite Cutting Machine,Granite Block Cutter.
