Yc-Sm41p in Wall Embedded Android Tablet 4 Inch Display Central Control Touch Screen AC Smart Home Control Panel for Home Automation
Basic Info.
Model NO.
YC-SM41P
Built-In Microphone
Built-In Microphone
Card Reader
Without Card Reader
Certification
Ce, ROHS
Cpu Core
Quad-Core
Cpu Type
Rockchip
Display Resolution
480*480
Drive Interface
USB 2.0
Fingerprint
Without Fingerprint
Front Camera Pixel
No
Hard Disk Capacity
32G
Memory
2GB
Network Mode
WiFi, RJ45
Operating System
Android
Rear Camera Pixel
No
Remote Control
Yes
Screen Size
4′′
Screen Type
Capacitive Screen
Speakers
Digital Amplifier Speaker
Security Protection
No
Voice Assistant
No
Warranty Period
1 Year
Webcam
Without Webcam
Dimension
84.5*84.5*36.2mm
CPU
Rk3566 Quad-Core Cortex-A55 up to 1.8GHz
System
Android 11/ Linux
RAM
2GB
ROM
32GB
Resolution
480*480
WiFi
802.11b/G/N
RS485
RS485 a, B
Power
AC 110~240V, 50Hz or Poe
Color
Black & White
Type C
USB Debug
Ethernet
10m/100m
Microphone
Microphone *2
Speaker
Speaker*2
Transport Package
Caron
Specification
1KG
Trademark
Portworld
Origin
Shenzhen, Guangdong, China
Production Capacity
100000PCS/Month
Packaging & Delivery
Package Size
30.00cm * 25.00cm * 6.00cm
Package Gross Weight
1.000kg
Product Description
Yc-Sm41p in Wall Embedded Android Tablet 4 Inch Display Central Control Touch Screen AC Smart Home Control Panel for Home automation Product Description CPU: RK3566 Quad-core Cortex-A55 Operating System: Android 11 / Linux Internal Storage: 2GB RAM, 32GB ROM Network: Ethernet, Bluetooth, WIFI Interface: RJ45, Type-C, RS485, Reset Application: Smart home, smart building, smart hotel, smart city, etc. Power supply: AC, POE Suitable for EU wall box and 86 wall box Customized functions: Light sensor, Temperature and humidity sensor, etc Product Parameters| 4 inch YC-SM41P | Dimension | 84.5*84.5*36.2mm |
| Display size | 4 inch | |
| CPU | 3566 Quad-core Cortex-A35 | |
| System | Android 11 | |
| Resolution | 480*480 IPS | |
| Touch Panel | Capactive touch panel | |
| RAM | 2G | |
| ROM | 32G | |
| WIFI | 802.11b/g/n | |
| Bluetooth | BT 4.0 | |
| Ethernet | 10M/100M | |
| RJ45 | Ethernet interface input (RJ-45 cable) | |
| Type C | Type C *1 | |
| RS485 | RS485*1 | |
| Reset | Reset *1 | |
| Speaker | Speaker *1 | |
| Microphone | Microphone *2 | |
| Power supply | POE ,IEEE802.3af | |
| AC 110~240V , 50HZ | ||
| Light sensor | Light sensor (Option) | |
| Temperature & humidity sensor | Temperature and humidity sensor (option) | |
| Install | In wall & Embedded | |
| Color | White color /Black Color | |
| Working temperature | .-10°~60° | |
| Language | Multi-languages support | |
| Working temperature | .-5°~70° |
Company Profile
FAQ 1. Can you accept sample order? A: Yes. 2. How long does it take to deliver the sample? A: It depends on different products, it usually takes 10-15 days. 3. What's your Mini Order Quantity(MOQ)? A: It depends on different products, for tablet pc 1000-2000 pieces. 4. What payment term you can accept? A: For sample, T/T or West Union is available, for big order by T/T, West Union or L/C. 5. How to ship the goods to us? A: For the sample or small quantity, by DHL For big order, normally by sea shipment or by air shipment. 6. Can we have our own logo printed on the product or package? A: For sample, it usually be neutral. For big order, it supports customized logo. 7. How much will the customized logo cost? A: For big order, if your quantity up to our MOQ, it usually be free. OEM / ODM are highly welcome! Trial order is acceptable! We are the factory, the price must be very competitive.
