Ks Pinge Polypropylene Solar Power Plants DC Link Film Capacitor for Wind

Ks Pinge Polypropylene Solar Power Plants DC Link Film Capacitor for Wind

US$24.21
50-99 Pieces
US$23.05
100+ Pieces

Basic Info.

Model NO.
DC LINK
Reference Standards
IEC 61071,IEC 60068,GB/T17702
Expected Life
> 100 000 H at Undc and 70ºC
Tolerance
+/- 5%(J) +/- 10%(K), +/-20%(M)(20ºC, 100Hz)
Color
Aluminum Original Color
Operating Temp.
-40~70ºC or 85ºC or 105ºC
Shape
Cylinder
Terminal
Screw or Nut
Shipment Method
Air and Sea
Service Life Time
10000 H
Transport Package
Master Carton
Specification
1100VDC 420μ F
Trademark
PinGe
Origin
Shunde China
Production Capacity
5000 PCS /Month

Packaging & Delivery

Package Size
42.00cm * 35.00cm * 35.00cm
Package Gross Weight
30.000kg

Product Description

1.Application Range The series of products apply to low self-inductance DC connection circuit and DC filter circuit.It can replace all kinds of electrolytic capacitors,extensively used in the power electronics industry,for PV Inverter,wind power converter,inversion welding machine,electrical locomotiveAuto-industry,UPS,EPS,SVG,etc.
Brand PinGe Model MKP-DL DC Link Capacitor
Rated Voltage 600VDC~2200VDC Capacitance Range 50μF to 1800 μF
Reference Standards IEC 61071,IEC 60068,GB/T17702 Application inductive charging systems, Solar systerms, welding machine
Type Dry Type Metalized Polypropylene Film Capacitor Expected Life > 100 000 h at UNDC and 70ºC
Tolerance ±5% Color Black or Grey
Terminal Screws or Nut Operating TEMP. -40~70ºC or 85ºC or 105ºC
Package Type Master Carton Shape Cylinder
Supplier Type Original Manufacturer Place of Origin Guangdong, China
2.Features Used in DC-Link filter circuits, can replace electrolytic capacitor Low ESR, high ripple current handling capabilities Low inductance Self-healing property Long lifetime Aluminum case, resin sealing
