High Quality TPU Layflat Water Hose Pump for Fire Fighting Pumpset

Product Description

High Quality TPU Layflat water Hose for fire fighting pumpset and movable self priming pumpProduct DescriptionStructures:
wrap and weft are high strength Polyester or Aramid fiber,TPU ling and cover are extruded by extruder simultaneously.
Production description

EX: TPU Layflat water Hose 4 inch
Size	Wall thickness (mm)	Weight(kg/m)	Working Pressure (WP)	Bursting pressure(BP)
4"(100)	3.9~4.1	1.4~1.8	1.6Mpa	4.8Mpa
Performance			Material

Features:
Durable and abrasive-resistance,oil-resistance,anti-corrosion,anti-aging,not rigid and fragile in the harsh cold condition, large size and flow and connecting easily,deploy and withdraw quickly,light weight,can replace the steels heavy pipe in using.
Applications:
The Hose can supporting our water pump series at the inlet and outlet:
1. SPDW series Movable selfpriming pump set for drainage water and well point.
2. Diesel engine pump set for flood, irrigation, water supply.
3. Fire fighting pump set for fire.
Working temperature:
-51°F ~176°F (-46ºC~80ºC)
Product ParametersProduct Specification

inch	Bore	Working Pressure			Burst Pressure			thickness	Weight	Length
	mm	MPa	BAR	PSl	MPa	BAR	PSL		Kg/m
1"	25+1.5	1.0/1.6	10/16	150/240	3.0/4.8	30/48	450/720	2.5~3.0	0.20~0.30	20~200
2"	51+1.5	1.0/1.6	10/16	150/240	3.0/4.8	30/48	450/720	2.5~3.0	0.29~0.55	20~200
2.5"	63.5+1.5	1.0/1.6	10/16	150/240	3.0/4.8	30/48	450/720	2.5~3.0	0.45~0.75	20~200
3"	76+2.0	1.0/1.6	10/16	150/240	3.0/4.8	30/48	450/720	2.8~3.5	0.60~1.0	20~200
4"	102+2.0	1.6/2.0/2.8	16/20/28	240/300/420	4.8/6.0/8.4	48/60/84	720/900/1260	4.0~5.0	1.0~1.80	20~200
5"	127+2.0	1.6	16	240	4.8	48	720	4.0~5.0	1.2~2.0	20~200
6"	152+2.0	1.6/2.8/4.2	16/28/42	240/420/630	4.8/8.4/8.4	48/84/84	720/1260/1260	3.9~5.5	2.0~4.0	20~200
8"	203+2.0	1.6/2.0	16/20	240/300	4.8/6.0	48/60	720/900	3.8~4.5	3.0~4.2	20~200
10"	254+3.0	1.3/1.6	13/16	195/240	3.9/4.8	39/48	585/720	4.6~5.5	4.2~6.0	20~200
12"	300+3.0	1.0/1.3	10/13	150/195	3.0/3.9	30/39	450/585	4.5~5.5	4.5~5.5	200
14"	356+4.0	0.5	5	75	1.5	15	225	3.5~4.0	3.5~4.3	20~200

Note: Parameters such as inner diameter, wall thickness, weight, pressure and color can be customized according to customer requirements.
Our Advantages1. Excellent production environment
2. Strict quality control system
Accordance to the ISO 9001:2015 Standard,and it takes the various detectors to test all procedures rigidly. In order to ensure the quality of every hose provided for users, company built a 200m testing platform,and it is equipped with 2 pressure testing experiment lines for testing of each hose.One-time extrusion molding, weave semi-finished products and TPU raw materials into the extrusion section, through a mold extrusion molding.The water pressure test
3. Uniformly coated inner and outer layer, no leaking.4. High tensile polyester yarn reinforced, high working pressure, low expansion.5. Inner and outer layers extruded at same time, excellent bonding, no delaminating.6. Assembled with different couplings.Anti-UV, No color changed.
Big wall thickness, striped surface, abrasion resistant, suitable for poor working condition.
Acid-base resistant, suitable for delivery of light chemicals in mining industry.
