Z3050X13 Factory Direct sale Radial Drilling Machine
| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Z3050X13
Controlling Mode
Artificial
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Manual
Precision
Normal Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Drill Capacity
50mm
Spindle travel
260mm
spindle taper
MT5
Spinde speed step
6
weight
2300kgs
Transport Package
Plywood Case
Specification
2300kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459590000
Production Capacity
5 PCS/Month
Product Description
RADIAL DRILLING MACHINE FEATURES:
Mechanical transmission
Mechanical / Electricity clamping
Mechanical speed
Automatic take-off and landing
Automatic feed
SPECIFICATIONS:
| MODEL | Z3050X13 |
| Max. drilling diameter | ø50mm |
| Colunu diameter | 300mm |
| Distance between spindle axis and column | 335-1300mm |
| Distance of headstock horizontal movement | 960mm |
| Distance between spindle nose and woring surface of base | 280-1170mm |
| Rocker arm lifting distance | 630mm |
| Spindle travel | 260mm |
| Spindle taper | MT 5 |
| Range of spindle speeds(6 steps) | 38,100,182,225,450,910r/min |
| Range of spindle feeds (3 steps) | 0.10,0.16,0.25mm/r |
| Max. permissible feed pressure of spindle | 6300N |
| Rocker arm lifting speed | 1.3m/min |
| Rocker swing angle | ±180° |
| Spindle motor power | 3 kW |
| Elevating motor power | 0.75kW |
| Cooling pump motor power | 0.04kW |
| Machine weight | 2300kg |
| Overall dimension | 2080x820x2320mm |
| Contact Us: |
| Miss Wynn Sales ManagerTENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 16678336698 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
