Crazy Selling Product Cold Oil Press Machine of Palm Fruit

Product Description

https://winglobal-machinery.en.made-in-china.com/product/kGzrujIvXMhP/China-Spiral-Oil-Expeller-Rapeseed-Peanut-Oil-Press-Machine.html
Product Description
Palm oil press machine is suitable for three types of customers
Suitable for home use, small investors, palm oil production business starters Suitable for small scale palm oil mill plant
Suitable for medium and large palm oil processing plants, Capacity: 5t/h ,10t/h, 30t/h, 45t/h, 60t/h, 120t/h
Engineers can design palm oil extraction process, equipment configuration solutions and workshop layout based on customers' actual requirement.

Main Features of palm oil extraction machine
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Running in a high automatization and intellectualization,no pollution
The process of this 3000kg/h palm oil extraction machine price:
Palm fruit bunches--Threshing---Sterilizing--Pressing--Clarifying--Filitering--Crude palm oil.
Detailed Photos
Palm oil press features
1.Fruit Reception: Initially, the palm fruit bunch is weighed and offloaded from trucks. Note that the fruits have to be weighed in order to calculate the purchasing costs. The bunches have to be carefully offloaded from the trucks because if they are mishandled their quality may significantly decrease and this will have a negative effect on the final product. Poorly handled palm fruits have high acid levels which not only interfere with the taste but also increase the cost of production because the acid levels have to be decreased to a certain minimum amount.
2.Threshing and Sterilizing: After that, the fruits undergo a process called "Threshing" where they are cut off from the bunch that holds them and they are put in boiling water with very high temperatures in order to "loosen" them. This process is what is known as - Sterilization by Pressurized Cooking. For starters, the threshing process can also be done manually to lower investment costs.
3.Palm Oil Extraction: The third step is the extraction of the palm oil in a screw palm fruit oil press machine. This step marks the peak of processing and the oil is extracted from the fruits by pulp pressing.
4.Oil Filtering: The extracted oil is then "Filtered and Purified" in order to remove dirt and other remains such as water and fruit shells. After the red palm oil is purified, it can be stored in barrels or gallons before being transported to the market.
Have machine in stock,order to get prompt delivery!
Product Parameters

Standard Technical Parameters

Model	PALM-3	Picture
Handling capacity	3000KG/H
Matching power	15KW
Internal dimensions	3100×1300×1200mm
Residual oil	6-8%
Belt type	3000-4000
Gross/Net Weight	2000kg

Palm oil press machine production line
Model	1	2-3	5	10
Residual oil	6-8%	6-8%	6-8%	6-8%
Belt type	3000-4000	3000-4000	3000-4000	3000-4000
Power	4KW	15KW	18.5KW	20KW
Product capacity	500kg/h	2000-3000kg/h	5000kg/h	10000kg/h
Weight	600kg	2000kg	3000kg	4000kg
Dimension	1200×1100×1300mm	3100×1300×1200mm	4000×1600×1400mm	5000×1950×1600mm

production process

1.The purpose is to separate the palm fruit bunches and pulp through the strong vibration of the rotating drum defroster.
2.The separated oil palm fruits are transported to the crushing section.

3.Sterilizing section: Palm fruit can go to bad easily if palm fruit are not processed within 2 days.Sterilizing can prevent palm fruit from going bad for a short time. In addition, palm fruit can become soft after sterilizing, which can press and produce palm oil easily.4.Pressing section: We have mini palm fruit press machine, this palm press machine can process 300-500kg palm fruit per hour.
5.Filtering section: After pressing, we can get crude palm oil. Our plate filter can remove the visible impurity in the crude palm oil.
This 300-500kg/h palm oil extraction machine price is our small type palm oil line. We also manufacture medium and large palm oil production line
1-5tph palm press line is a new small scale palm oil processing machine designed by the engineers of Henan Winglobal Machinery & Equipment CO.,LTD. It uses the international advanced and mature palm oil extraction technology to extract palm oil. Suitable for small palm oil plant and palm oil production enterprises. What's more, the palm oil processing machinery is low cost and high productivity.

Company Profile
Henan Winglobal Machinery a fully integreated factory enterprise of design, manufacturing and sales of oil presses. It is designated by the former Ministry of Industrial Machinery as the recognised oil press manufacturing base, with 40 years history till now.We are proud of our sophisticated equipment and rich technical expertise. Guided by the principle of "Dependable Quality, Reasonable Price, Timely Delivery, Considerate Aftersales", we have established firm and ever growing relationships with customers both at home and abroad.We passed ISO in 2000, and in 2008 we achieved CE certificate. With our strength, our oil press products come with less energy consumption, and best oil yield rate. The oil press can be used to squeeze oil from all types of granular or powder oil seeds, including soybean, peanut, sunflower seeds, tung seeds, mustard seeds, castor seeds, palm fruit, palm kernel/fibre, coconut, rapeseeds, moringa etc.Apart from the above, we also manufacture the combined automatic oil press, auxiliaries of all sorts, palm oil processing complete line, oil refinery set and so on.
Why Choose us

Our Advantages:
PRICE
Absolute Advantage of Price .Excellent Quality and Reasonable Price.
SERVICE
Perfect After-sale Service. Professional R&D Productions/Sales Team.
QUALITY ASSURANCE
We have carried out strict inspection of every part and product,trying to have no quality problems in the hands of customers.
PROFESSIONALITY
Can be customized according to customer needs.Ripple in the world,and because of you.
FAQ
Q: Can you help chose suitable products?
A: Yes. We have many experts who have worked in this field for many years. They can help you select the most suitable products according to your actual condition. And they can design proper process flow based on your special situation. If necessary, we can even send professionals to your local place for site planning and work-flow design.
Q: How about the quality of your products?
A:We put the quality in the first place based on the honesty. Our machines are manufactured strictly according to national and international standards, and we take a test on each equipment before the delivery. You can also use Trade Assurance for product quality protection, punctual shipment protection and payment protection.
Q: How about the price?
A: We pursue small profits but quick turnover, and we can give you lower price than other trading companies. If the product is really suitable and can benefit you, the price is negotiable.
Q: If I don't know how to operate this machine? How can I do?
A: Our machine has been tested OK and fully assembled before.
A: Shipping, customer just needs to make2~4 hours wear-in and then can work.
Q:Can I use the machine to extract several kinds of raw materials?
A:Yes, sure, as sesame, sunflower, peanut, coconut, soybean, ect.
