S5720-12TP-PWR-LI-AC huawei switch poe swicth

Product Details

Product Description

Product Description
Product Overview for S5720-12TP-PWR-LI-AC

Product	S5720-12TP-PWR-LI-AC
Product Description	S5720-12TP-PWR-LI-AC(8 Ethernet 10/100/1000 PoE+ ports.2 Gig SFP and 2 dual-purpose 10/100/1000 or SFP.124W PoE AC 110/220V)
Dimensions (W x D x H)	320 mm x 220 mm x 43.6 mm
Input Voltage	AC:Rated voltage range: 100V to 240V; 50/60 Hz Maximum voltage range: 90V to 264V; 47 Hz to 63 Hz
Maximum Power Consumption	Without PoE power output: 15.61W With PoE power output: 160.5W (PoE: 123.2W)
Typical Power Consumption (without PoE)	14.57W
Operating Environment	Operating temperature: 0m to 1,800m altitude: -5°C to +45°C 1,800m to 5,000m altitude: The operating temperature reduces by 1°C for each 220m increase in altitude. Relative humidity: 5% to 95% (non-condensing)
Heat Dissipation	Natural heat dissipation without fans

Model and appearance
Service featuresItemDescription

MAC Address Table	16K MAC address entries
	MAC address learning and aging
	Static, dynamic, and blackhole MAC address entries
	Packet filtering based on source MAC addresses
	Interface-based MAC learning limiting
VLAN Features	4094 VLANs
	Guest VLAN and voice VLAN
	GVRP
	MUX VLAN
	VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and interfaces
	1: 1 and N: 1 VLAN mapping
Jumbo Frame	10K
Ethernet Loop Protection	RRPP ring topology and RRPP multi-instance
	Smart Link tree topology and Smart Link multi-instance, providing millisecond-level protection switchover
	SEP
	ERPS (G.8032)
	STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s)
	BPDU protection, root protection, and loop protection
	BPDU tunnel
Multicast	PIM DM, PIM SM, PIM SSM
	IGMPv1/v2/v3 and IGMPv1/v2/v3 snooping
	MLD v1/v2 and MLDv1/v2 snooping
	Multicast forwarding in a VLAN and multicast replication between VLANs
	Multicast load balancing among member ports of a trunk
	Controllable multicast
	Interface-based multicast traffic statistics
IP Routing	Static route, RIP, RIPng, OSPF, and OSPFv3
IPv6 Features	Neighbor Discovery (ND)
	Path MTU (PMTU)
	IPv6 ping, IPv6 tracert, and IPv6 Telnet
Reliability	EFM OAM (802.3ah)
	CFM OAM (802.1ag)
	ITU-Y.1731
	DLDP
	LACP
QoS/ACL	Rate limiting on packets sent and received by an interface
	Packet redirection
	Interface-based traffic policing and two-rate and three-color CAR
	Eight queues on each interface
	WRR, DRR, SP, WRR + SP, and DRR + SP queue scheduling algorithms
	Re-marking of the 802.1p priority and DSCP priority
	Packet filtering at Layer 2 to Layer 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type, and VLAN ID
	Rate limiting in each queue and traffic shaping on interfaces
Security	Hierarchical user management and password protection
	DoS attack defense, ARP attack defense, and ICMP attack defense
	Binding of the IP address, MAC address, interface number, and VLAN ID
	Port isolation, port security, and sticky MAC
	MFF
	Blackhole MAC address entries
	Limit on the number of learned MAC addresses
	IEEE 802.1x authentication and limit on the number of users on an interface
	AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC
	SSH V2.0
	Hypertext Transfer Protocol Secure (HTTPS)
	CPU defense
	Blacklist and whitelist
	DHCP relay, DHCP server, and DHCP snooping
	DHCPv6 relay, DHCPv6 server, and DHCPv6 snooping Supports separation between user authentication and policy enforcement points
Lightning Protection	Service interface: 7 kV
Super Virtual Fabric (SVF)	Working as an SVF client that is plug-and-play with zero configuration
	Automatically loading the system software package and patches of clients One-click
	and automatic delivery of service configurations
	Supports independent running client
Management and Maintenance	iStack
	Virtual Cable Test (VCT)
	Remote configuration and maintenance using Telnet
	SNMPv1/v2c/v3
	RMON
	eSight and web-based NMS
	HTTPS
	LLDP/LLDP-MED
	System logs and multi-level alarms
	802.3az EEE
	Dying Gasp (S5720-X-LI series)
Interoperability	Supports VBST (Compatible with PVST/PVST+/RPVST)
	Supports LNP (Similar to DTP)
	Supports VCMP (Similar to VTP)
