R290 Inverter Pool Heater Swimming Pool Heat Pump Water Heater Low Gwp

Product Description

Product Description This innovative full inverter air to water swimming Pool Heat Pump applies R290 refrigerant for the very FIRST time. HEEALARX is the leading enterprise in the heat pump industry to apply R290 refrigerant to swimming pool heat pumps thanks to its edgy technology.
Our product of R290 Full inverter pool heat pump HEEALARX Series takes patented technoloy of UNIQUE shape air flow system which can provide fast heating/cooling the swimming pool with Low noise level.

Product Parameters

Model	VS120INR	VS180INR	VS250INR	VS300INR
Power Supply	220V-240V~/50Hz			380V-415V~/3N/50Hz
Performance Condition (Air 26ºC/Water26ºC/Humid,80%)
Heating Capacity (kW)	12.0	16.0	22.0	30.0
Consumed power	1.99	2.63	3.61	4.96
COP	6.04	6.08	6.10	6.05
Performance Condition (Air 15ºC/Water26ºC/Humid,70%)
Heating Capacity (kW)	9.0	12.0	16.5	22.5
Consumed power	2.07	2.73	3.73	5.11
COP	4.35	4.40	4.42	4.40
Performance Condition (Air 2ºC/Water26ºC/Humid,83%) Crunning 15min
Heating Capacity (kW)	6.5	8.6	11.8	16.0
Consumed power	1.84	2.44	3.37	4.60
COP	3.47	3.53	3.50	3.48
Performance Condition (Air -7ºC/Water26ºC/Humid,73%)
Heating Capacity (kW)	5.0	6.7	9.3	12.6
Consumed power	1.60	2.12	2.95	4.05
COP	3.13	3.16	3.15	3.11
Performance Condition (Air 35ºC/Water30ºC)
Cooling Capacity (kW)	6.4	8.5	11.5	15.5
Consumed power	2.32	3.04	4.14	5.64
COP	2.76	2.80	2.78	2.75
Max Power Input (kW)	3.00	3.60	4.40	5.00
Max Current Input (A)	13.04	15.70	19.10	7.60
Refrigerant	R290
Casing type	Galvanized steel with paintings
Compressor	DC type
Fan Form	DC type
Fan Quantity	1	1	1	1
Fan Speed (RPM)	400-800	400-800	400-800	400-800
Sound Pressure 1m dB(A)	40-50	40-51	41-53	42-55
Sound Pressure 10m dB(A)	21-31	21-33	23-35	24-37
Water Connection (mm)	50	50	50	50
Water Flow Volume (m³/h)	4.0	5.3	7.3	9.9
Net Dimensions L/W/H (mm)	1060*480*800		1060*480*1020
Package Dimensions L/W/H (mm)	1150*550*950		1150*550*1170
Net/Poids Weight (kg)	80/95	85/100	100/115	110/125
Qty per 20GP/40GP/40HQ/45HQ	40/84//84/96	40/84//84/96	40/84//84/96	40/84//84/96
Advised pool volume(m³)	25-45	35-60	50-85	65-120
Operating air temperature	-7ºC~43ºC
Heating temperatuer range	15ºC~40ºC
Cooling temperatuer range	8ºC~28ºC
WIFI	YES
The data above is for reference only. The specifications are subiect to change without prior notice. For actual specificaions of unit, please refer to the stickers on the unit

Parts we are using:
1) PVC Titanium heat exchanger with full resistance against corrosion, more durable.
2) Compact structure, easy demountable for access.
3) High efficiency compressor with R290 refrigerant.
4) Flow switch for water flow protection.
5) Intelligent controller and adjustment by quick mind
6) Intelligent digital touch controller with wifi
7) Air exchanger (fins-coil) with hydrophilic coating.
8) Automatic defrosting function included. (With reverse cycle valve inside)
9) General testing and operational test carried out for every unit before package in the factory.



Installation Instruction for Reference:
FAQ:
*Can we add our brand.
Yes, We will add your brand for order qty of 10pcs. If need, need pay extra charge for printed items.
* What place is your factory located in China?
factory is located in Guangdong
*How many production line and lab do you have ?
Seven production lines and One National laboratory.

*What others products do you have?
Residential swimming pool heat pump, commercial swimming pool heat pump and house heating and cooling inverter air to water heat pumps. , heat pump top kit, EVI heat pump, Etc. Which can meet the different demands from industrial, commercial and residential application.

* How long is your warranty?
Three years warranty and long term technical support.

*What kind of payment term do you offer?
30% deposit in avance and the balance need to be paid before shipment.

Mature Full Inverter Technology
After 8 years of research, designing and advancement by our international engineer team from Singapore and China, HEEALARX has fully mastered the secret of the mature full inverter technology and also it has applied to our different category of heat pump products, including swimming pool heat pump, house heating and cooling heat pump monobloc and split type, and commercial type pool heat pumps. With mature full inverter technology the energy efficiency of our full range of heat pump can be improved up to 20%-60% more, bringing great energy savings and also cost savings to our customers.
Certifications
Brief Introduction regarding HEEALARX INDUSTRY LIMITED

CE & A+++ Certified by TUV

Whole range of split type full inverter air water house heating heat pump has got CE certified and also got A+++ Certified by TUV. World famous parts such as top famous brandplate heater exchanger, inverter water pump and also Panasonic full inverter compressor with evi are adopted to ensure the high quality and good performance of the whole range of split type full inverter air water heat pump with evi.
