560X1730 Four Peripheral Drilled Rollers Auto Rubber Calender Machine for Rubber Sheet

Product Description

Product Description
560X1730 Four Peripheral Drilled Rollers AUTO Rubber Calender Machine For rubber sheet
LANHANG BRAND rubber calender is an important equipment in rubber processing.
It is mainly used to make the mixed rubber into a film with a certain thickness and width through the calendering effect, or to cover and paste the textile fabrics, steel wires and other reinforcing materials on the film to make composite films.
This machine consists of roller, frame, transmission system, heating and cooling system, lubrication system and control system and other parts. The roller is the core component of the calender, and the factors such as the surface finish, temperature control and the speed ratio between the rollers have a crucial impact on the quality of the calendered products.
During work, the rubber realizes the change of thickness and shape through the extrusion and extension between the rollers. At the same time, the temperature of the rubber is precisely controlled through the heating and cooling system to meet the requirements of the processing technology.
The performance and accuracy of the rubber calender directly affect the quality and production efficiency of the rubber products, and are widely used in the production process of rubber products such as tires, rubber conveyor belts, and rubber seals.
Our Advantages

Application&Features:
Mainly used for film, rigid sheet calendering. Why Choose Four rollers calender from Lanhang:
1. Since1992, with more than 20 years' professional experience
2. Overseas service center available (in Europe, Japan, Dubai, etc.)
3. International CE, SGS, IAF, CNAS certification
4. National high-tech enterprise / products
5. Various National Patent for Inventions Letters for rubber & plastic machinery
6. ISO9001:2008 management
Product Parameters

Main Parameters :

Project/Model	SY610x1900	SY610x2030	SY660x2500	SY710x2800
Roll specification(mm)	Ф610x1900	Ф610x2030	Ф660x2500	Ф710x2800
Layout of the roll	The pour L type
Roll speed(m/min)	40-100	40-100	50-120	50-120
Final product thickness(mm)	0.08-1	0.08-1	0.08-1	0.08-1
Final product width(mm)	1500	1600	2100	2300
Power(kw)	200kw (45kw2sets 55kw2sets)	60kw (55kw2sets 75kw2sets)	330kw (75kw2sets 90kw2sets)	400kw (90kw2sets 110kw2sets)
